Артикул
Название
Примечание
Количество
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0 TO Y1610-03A0.
-1шт.
|$2
705-32-37430
PUMP ASS'Y,(SAR71)
SN: 17743-UP
1шт.
1
0
BRACKET
SN: 17743-UP
1шт.
3
0
CARRIER ASS'Y
SN: 17743-UP
1шт.
6
0
GEAR,DRIVE
SN: 17743-UP
1шт.
7
0
GEAR,DRIVEN
SN: 17743-UP
1шт.
11
0
BOLT
SN: 17743-UP
4шт.
15
705-19-03710
BOLT
SN: 17743-UP
4шт.
16
705-17-04980
WASHER
SN: 17743-UP
4шт.
17
705-17-03880
PLATE
SN: 17743-UP
1шт.
1
195-79-51131
BEAM
2
195-78-71220
BUSHING
3
195-78-21171
PLATE
4
01010-62040
BOLT
5
01643-32060
WASHER
6
195-78-41320
SEAL, DUST,DUST
7
195-78-71180
PIN
8
195-79-52140
PIN
9
175-79-61160
PLATE
10
01010-81030
BOLT
11
01643-51032
WASHER
12
195-79-52110
COLLAR
13
195-79-52130
PIN
14
04050-16040
PIN
15
195-78-72371
ARM
16
195-78-71220
BUSHING
17
195-78-71210
PIN
18
07020-00000
FITTING
19
195-78-21171
PLATE
20
01010-62040
BOLT
21
01643-32060
WASHER
22
195-78-41320
SEAL, DUST
23
195-79-51151
SHANK
24
195-78-71360
PIN
25
195-78-71111
PROTECTOR
26
195-78-71360
PIN
27
195-78-71320
POINT
28
195-78-71380
SHANK,SERVICE PARTS
Выбрано товаров: 53
