Запчасти Komatsu D375A-5D СИЛОВАЯ ЛИНИЯ МАСЛ. ОБОГРЕВАТЕЛЬ. РАЗНОЕ
№
Артикул
Название
Примечание
Количество
1
195-06-43121
BRACKET
SN: 17743-UP
1шт.
4
175-06-39830
CAP
SN: 17743-UP
1шт.
5
01220-40312
SCREW
SN: 17743-UP
1шт.
6
01601-20307
WASHER
SN: 17743-UP
1шт.
8
01220-40312
SCREW
SN: 17743-UP
4шт.
9
01601-20307
WASHER
SN: 17743-UP
4шт.
10
01220-40610
SCREW
SN: 17743-UP
1шт.
23
195-98-14780
PLATE, CAUTION
SN: 17743-UP
1шт.
24
02721-11617
PLUG,WITHOUT HEATER
SN: 17743-UP
2шт.
|$3
195-72-00020
BLADE ASS'Y
1
BLADE
2
195-71-74121
BRACKET (WELDED)
3
195-71-74141
BRACKET (WELDED)
4
195-71-74151
BRACKET (WELDED)
5
195-71-71161
BRACKET (WELDED)
6
195-71-71171
BRACKET (WELDED)
7
195-71-71313
BRACKET (WELDED)
8
17M-71-22280
TRUNNION (WELDED)
9
195-72-61120
PLATE (WELDED)
10
195-72-61130
PLATE (WELDED)
11
195-72-61140
PLATE (WELDED)
12
195-72-61150
PLATE (WELDED)
13
195-72-61160
PLATE (WELDED)
14
195-72-61170
PLATE (WELDED)
15
195-72-61190
PLATE (WELDED)
16
195-72-61210
PLATE (WELDED)
17
198-72-11151
STOPPER (WELDED)
18
195-71-74270
BUSHING
19
195-71-74160
BUSHING
|$23
195-71-00710
BRACKET ASS'Y
20
BUSHING
21
BRACKET
22
07020-00000
FITTING
23
07049-01620
PLUG
24
195-71-00560
SHIM ASS'Y
|$30
SHIM, 2.0MM
|$31
SHIM, 1.0MM
|$32
SHIM, 0.5MM
25
01011-62720
BOLT
26
01643-32780
WASHER
27
195-71-71641
PIN
28
195-71-71630
PLATE
29
01010-82470
BOLT
30
01643-32460
WASHER
31
195-71-71220
PIN
32
07049-02025
PLUG
33
195-71-74290
LOCK
34
01010-62045
BOLT
35
195-71-61590
PIN
36
195-71-51450
LOCK
37
01010-62050
BOLT
38
01643-32060
WASHER
39
198-71-11181
EDGE
40
198-71-21710
BOLT
41
195-71-61950
NUT
42
198-71-11230
WASHER
43
198-72-11181
EDGE
44
195-71-61930
BIT
45
198-71-21720
BOLT
46
195-71-61950
NUT
47
198-71-11230
WASHER
48
195-71-61940
BIT
49
09601-60000
PLATE, NAME
50
04418-13060
SCREW
