Запчасти Komatsu D375A-5D ЗАЩИТА ОТ ВАНДАЛИЗМА РАЗНОЕ

1

14X-06-12160

SWITCH

SN: 17743-UP

2шт.

2

14X-06-12190

SWITCH

SN: 17743-UP

1шт.

3

114-06-42310

SWITCH

SN: 17743-UP

1шт.

4

09460-00002

LOCK

SN: 17743-UP

1шт.

|$3

195-71-00740

BLADE ASS'Y

1

BLADE

2

195-71-74121

BRACKET (WELDED)

3

195-71-74141

BRACKET (WELDED)

4

195-71-74151

BRACKET (WELDED)

5

195-71-71161

BRACKET (WELDED)

6

195-71-71171

BRACKET (WELDED)

7

195-71-71314

BRACKET (WELDED)

8

17M-71-22280

TRUNNION (WELDED)

9

195-71-71320

PLATE (WELDED)

10

195-71-61650

PLATE (WELDED)

11

195-71-61660

PLATE (WELDED)

12

195-71-61680

PLATE (WELDED)

13

195-71-61690

PLATE (WELDED)

14

195-71-51530

PLATE (WELDED)

15

198-72-11151

STOPPER (WELDED)

16

195-72-72320

PLATE (WELDED)

17

195-71-72331

PLATE (WELDED)

18

195-71-72341

PLATE (WELDED)

19

195-71-72350

PLATE (WELDED)

20

195-71-72360

PLATE (WELDED)

21

195-71-71220

PIN

22

07049-02025

PLUG

23

195-71-74290

LOCK

24

01010-62045

BOLT

25

195-71-61590

PIN

26

195-71-51450

LOCK

27

01010-62050

BOLT

28

01643-32060

WASHER

29

195-71-74270

BUSHING

30

195-71-74160

BUSHING

31

195-71-74281

BRACKET

32

195-71-00560

SHIM ASS'Y

32

SHIM, 2.0MM

32

SHIM, 1.0MM

32

SHIM, 0.5MM

33

01011-62720

BOLT

34

01643-32780

WASHER

35

195-71-71641

PIN

36

195-71-71630

PLATE

37

01010-82470

BOLT

38

01643-32460

WASHER

39

07020-00000

FITTING

40

07049-01620

PLUG

41

195-71-74160

BUSHING

42

195-71-61550

EDGE

43

198-71-21710

BOLT

44

195-71-61950

NUT

45

198-71-11230

WASHER

46

198-72-11181

EDGE

47

198-71-21710

BOLT

48

195-71-61950

NUT

49

198-71-11230

WASHER

50

195-71-61930

BIT

51

198-71-21720

BOLT

52

195-71-61950

NUT

53

198-71-11230

WASHER

54

195-71-61940

BIT

55

198-71-21720

BOLT

56

195-71-61950

NUT

57

198-71-11230

WASHER

58

09601-60000

PLATE, NAME

59

04418-13060

SCREW
