Запчасти Komatsu D375A-5D УПРАВЛ-Е РЫХЛИТЕЛЕМ (№89-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

17A-98-11160

PLATE

SN: 17743-UP

1шт.

2

04434-53412

CLIP

SN: 17743-UP

1шт.

3

01010-81230

BOLT

SN: 17743-UP

1шт.

4

01643-31232

WASHER

SN: 17743-UP

1шт.

1

198-911-9610

HEATER ASS'Y

2

198-911-9111

BLOWER ASS'Y

3

198-911-9151

DUCT

4

198-911-9390

DAMPER

5

198-911-9620

CONTROL ASS'Y

6

20Y-979-3380

FILTER

7

198-911-9240

RELAY, 4-TERMINAL

8

198-911-9230

COVER

9

198-911-9210

CABLE

10

198-911-9630

COVER

11

198-911-9650

COVER

12

14X-54-18270

GRILLE ASS'Y

13

195-911-8212

BRACKET

14

198-911-9131

COVER

15

01435-00814

BOLT

16

198-911-9271

BRACKET

17

01023-20614

SCREW

18

195-911-9160

DUCT

19

01010-80820

BOLT

20

01643-30823

WASHER

21

198-911-9352

PLATE

22

01435-01230

BOLT

23

09459-11033

LOCK

24

09459-01614

SPRING

25

01642-01016

WASHER

26

04050-03015

PIN

27

198-911-9121

COVER

28

142-54-13640

HINGE (WELDED)

29

01010-80816

BOLT

30

01643-30823

WASHER

31

01010-80612

BOLT

32

01643-30623

WASHER

33

01010-80816

BOLT

34

01010-80820

BOLT

35

01010-80825

BOLT

36

01643-30823

WASHER

37

01023-10510

SCREW

38

01010-81235

BOLT

39

01643-31232

WASHER
