Запчасти Komatsu D375A-5D ТЕРМОС КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

195-911-1722

FLASK

SN: 17743-UP

1шт.

1

198-Z11-2941

COVER

2

198-Z11-2951

COVER

3

01245-00616

SCREW

4

01643-70623

WASHER

5

14X-911-5911

SEAL

6

198-Z11-3540

SEAL

7

01010-D1230

BOLT

8

01643-71232

WASHER

9

198-Z11-2961

PLATE

10

01010-D1230

BOLT

11

01643-71232

WASHER

12

14X-911-5711

BRACKET

13

14X-911-5721

BRACKET

14

203-43-56450

CAP, PEDAL

15

01010-D1230

BOLT

16

01643-71232

WASHER

17

198-Z11-3341

BRACKET

18

198-Z11-5770

BRACKET

19

01010-D1230

BOLT

20

01643-71232

WASHER

21

14X-911-1921

STRIKER

22

01580-11008

NUT

23

01643-31032

WASHER

24

130-911-1720

STOPPER

25

01580-11210

NUT

26

198-Z11-5930

COVER

27

198-Z11-5940

COVER

28

198-Z11-2892

COVER

29

01245-00820

SCREW

30

01643-70823

WASHER

31

198-Z11-2850

HANDLE

32

198-Z11-3990

BRACKET

33

01435-30825

BOLT

34

14X-911-6161

BOX

35

01245-00820

SCREW

36

01643-70823

WASHER

37

20G-54-13420

ASHTRAY

38

08913-02401

LIGHTER

39

195-54-68281

PLATE

40

01245-00616

SCREW

41

01643-70623

WASHER

42

198-911-9510

DAMPER ASS'Y

43

198-911-9520

DAMPER ASS'Y

44

01010-D1230

BOLT

45

01643-71232

WASHER
