Запчасти Komatsu D375A-5 КЛАПАН ТРАНСМИССИИ (/)¤ НИЖН. КЛАПАН СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$3

195-15-71001

TRANSMISSION ASS'Y

SN: (107731)-UP

1шт.

|$4

195-15-71000

TRANSMISSION ASS'Y

SN: 18001-(107730)

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-64A0.

-1шт.

|$9

195-15-75101

T/M VALVE ASS'Y,TRANSMISSION

SN: (107731)-UP

1шт.

|$11

195-15-75505

CONTROL VALVE ASS'Y,TRANSMISSION

SN: 18713-(107730)

1шт.

|$12

0

CONTROL VALVE ASS'Y,TRANSMISSION

SN: (18713-18957)

1шт.

|$13

0

CONTROL VALVE ASS'Y,TRANSMISSION

SN: (106886)-00018712

1шт.

|$14

0

CONTROL VALVE ASS'Y,TRANSMISSION

SN: (106709)-(106885)

1шт.

|$15

0

CONTROL VALVE ASS'Y,TRANSMISSION

SN: (6481)-(106708)

1шт.

|$16

0

CONTROL VALVE ASS'Y,TRANSMISSION

SN: 18001-(6480)

1шт.

|$$12

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-59A0 TO F2320-61A0.

-1шт.

|$18

195-15-00323

VALVE ASS'Y,LOWER

SN: 18958-UP

1шт.

|$19

195-15-00322

VALVE ASS'Y,LOWER

SN: (106709)-00018957

1шт.

|$20

0

VALVE ASS'Y,LOWER

SN: (6481)-(106708)

1шт.

|$21

0

VALVE ASS'Y,LOWER

SN: 18001-(6480)

1шт.

1

0

BODY,VALVE

SN: (106709)-UP

1шт.

1

0

BODY,VALVE

SN: 18001-(106708)

1шт.

2

0

SOLENOID

SN: 18001-UP

2шт.

3

0

SPOOL

SN: 18958-UP

2шт.

3

0

SPOOL

SN: 18001-18957

2шт.

4

0

SPRING

SN: 18001-UP

2шт.

5

0

SHIM, 0.5MM

SN: 18001-UP

8шт.

6

0

SHIM, 0.2MM

SN: 18001-UP

8шт.

7

0

PLUG

SN: 18001-UP

2шт.

8

0

VALVE

SN: (6481)-UP

2шт.

8

0

VALVE

SN: 18001-(6480)

2шт.

9

0

BALL

SN: 18001-UP

2шт.

10

0

O-RING (K3)

SN: 18001-UP

2шт.

11

0

PLUG

SN: 18001-UP

1шт.

12

195-15-76330

FILTER

SN: 18713-UP

5шт.

13

195-15-76320

SLEEVE

SN: 18713-UP

5шт.
