Запчасти Komatsu D375A-5 СИЛОВАЯ ПЕРЕДАЧА (8/)¤ КОНЦЕНТР. ТРУБЫ (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$3

195-00-00550

POWER TRAIN ASS'Y

SN: 18001-UP

1шт.

|$4

195-00-00560

POWER TRAIN ASS'Y,(WITH HEATER)

SN: 18001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2300-51A0 TO F2300-60A0.

-1шт.

1

195-49-52110

BLOCK

SN: 18001-UP

1шт.

2

203-62-21720

SPACER

SN: 18001-UP

2шт.

3

195-49-36120

NIPPLE

SN: 18001-UP

14шт.

4

203-62-21740

NIPPLE

SN: 18001-UP

14шт.

5

01010-81245

BOLT

SN: 18001-UP

1шт.

6

01643-31232

WASHER

SN: 18001-UP

1шт.

7

01011-81220

BOLT

SN: 18001-UP

1шт.

8

01643-31232

WASHER

SN: 18001-UP

1шт.

|$20

195-49-52120

HOSE ASS'Y

SN: 18001-UP

1шт.

9

17A-49-17151

HOSE, 1450MM,WHITE-RED

SN: 18001-UP

1шт.

10

17A-49-17510

HOSE, 1300MM,WHITE-BLUE

SN: 18001-UP

1шт.

11

17A-49-17510

HOSE, 1300MM,YELLOW-BLACK

SN: 18001-UP

1шт.

12

17A-49-17631

HOSE, 1400MM,WHITE-YELLOW

SN: 18001-UP

1шт.

13

17A-49-17631

HOSE, 1400MM,RED-BLUE

SN: 18001-UP

1шт.

14

17M-22-28331

HOSE, 900MM

SN: 18001-UP

1шт.

15

17M-49-14260

HOSE, 1000MM,YELLOW-RED

SN: 18001-UP

1шт.

16

17M-49-14260

HOSE, 1000MM,YELLOW-BLUE

SN: 18001-UP

1шт.

17

195-49-36431

HOSE, 800MM,BLUE

SN: 18001-UP

1шт.

18

195-49-36440

HOSE, 1200MM,RED

SN: 18001-UP

1шт.

19

195-49-36460

HOSE, 2400MM,WHITE

SN: 18001-UP

1шт.

20

195-49-36470

HOSE, 2500MM,WHITE-BLACK

SN: 18001-UP

1шт.

21

195-49-36470

HOSE, 2500MM,BLACK

SN: 18001-UP

1шт.

22

195-49-36480

HOSE, 2600MM,YELLOW

SN: 18001-UP

1шт.
