Запчасти Komatsu D375A-3 ТРАНСМИССИЯ СМАЗЫВ. КЛАПАН СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

195-15-03012

TRANSMISSION ASS'Y,(B)

SN: 17261-UP

1шт.

|$10

195-15-03011

TRANSMISSION ASS'Y

SN: 5752-17260

1шт.

|$11

0

TRANSMISSION ASS'Y

SN: 17001-(5751)

1шт.

|$12

195-15-51072

TRANSMISSION ASS'Y

SN: 17555-UP

1шт.

|$13

195-15-51071

TRANSMISSION ASS'Y

SN: 17261-17554

1шт.

|$14

195-15-51070

TRANSMISSION ASS'Y,(B)

SN: 17001-17260

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-62A0.

-1шт.

|$16

195-15-51003

TRANSMISSION ASS'Y,FOR SEVEN TRACK ROLLER

SN: 17501-UP

1шт.

|$$10

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 55A0, 56A2, AND 57A0 TO 62A0.

-1шт.

|$21

561-15-00840

VALVE ASS'Y,LUBRICATION

SN: 17001-UP

1шт.

1

0

BODY,VALVE

SN: 17001-UP

1шт.

2

07042-20108

PLUG

SN: 17001-UP

1шт.

3

561-15-54230

VALVE

SN: 17001-UP

1шт.

4

103-40-21211

SPRING

SN: 17001-UP

1шт.

5

232-15-14280

PLUG

SN: 17001-UP

1шт.

6

07002-02434

O-RING (K6)

SN: 17001-UP

1шт.

7

07000-73035

O-RING (K6)

SN: 17001-UP

3шт.

8

01010-81065

BOLT

SN: 17001-UP

3шт.

9

01643-31032

WASHER

SN: 17001-UP

3шт.
