Запчасти Komatsu D375A-3-01 ТРАНСМИССИЯ (/8)¤ КОЖУХ (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

195-15-03012

TRANSMISSION ASS'Y,(B)

SN: 17261-UP

1шт.

|1

195-15-03011

TRANSMISSION ASS'Y

SN: 5752-17260

1шт.

|1

0

TRANSMISSION ASS'Y

SN: 17001-(5751)

1шт.

|1

195-15-51072

TRANSMISSION ASS'Y

SN: 17555-UP

1шт.

|1

195-15-51071

TRANSMISSION ASS'Y

SN: 17261-17554

1шт.

|1

195-15-51070

TRANSMISSION ASS'Y,(B)

SN: 17001-17260

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-62A0.

-1шт.

|1

195-15-51003

TRANSMISSION ASS'Y,FOR SEVEN TRACK ROLLER

SN: 17501-UP

1шт.

|$$10

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 55A0¤ 56A2¤ AND 57A0 TO 62A0.

-1шт.

1

195-15-51130

HOUSING

SN: 17001-UP

1шт.

2

175-15-59250

RING,SEAL (K3)

SN: 17001-UP

1шт.

3

195-15-29220

RING,SEAL (K3)

SN: 17001-UP

1шт.

4

195-15-42741

PISTON

SN: 17001-UP

1шт.

5

04020-01228

PIN,DOWEL

SN: 17001-UP

6шт.

6

195-15-42980

SPRING

SN: 17001-UP

12шт.

7

175-15-42880

SPRING

SN: 17001-UP

114шт.

8

195-15-42721

DISC

SN: 17001-UP

7шт.

9

195-15-42721

DISC

SN: 17001-UP

12шт.

10

195-15-42780

PLATE

SN: 17001-UP

15шт.

|11

17M-15-00250

PLATE ASS'Y

SN: 17001-UP

1шт.

11

0

PLATE

SN: 17001-UP

1шт.

12

145-14-11320

PLUG

SN: 17001-UP

2шт.

13

175-15-31210

PIN

SN: 17001-UP

2шт.

|14

17M-15-00240

HOUSING ASS'Y

SN: 17001-UP

1шт.

14

0

HOUSING

SN: 17001-UP

1шт.

15

145-14-11320

PLUG

SN: 17001-UP

2шт.

16

582-15-19250

RING,SEAL (K3)

SN: 17001-UP

1шт.

17

195-15-39210

RING,SEAL (K3)

SN: 17001-UP

1шт.

18

175-15-59270

RING,SEAL (K3)

SN: 17001-UP

1шт.

19

195-15-42751

PISTON

SN: 17001-UP

1шт.

20

195-15-42764

PISTON

SN: (6256)-UP

1шт.

|20

195-15-42763

PISTON

SN: 17001-(6255)

1шт.

21

561-15-51310

SLEEVE

SN: 17001-UP

17шт.

22

195-15-29220

RING,SEAL (K3)

SN: 17001-UP

1шт.

23

07000-73022

O-RING (K4)

SN: 17001-UP

5шт.

24

195-15-42790

PLATE

SN: 17001-UP

3шт.

25

145-14-33731

SPRING¤ (L= 70.0)

SN: 17001-UP

12шт.

26

135-15-22820

PIN

SN: 17001-UP

6шт.

27

144-15-22760

PIN

SN: 17001-UP

6шт.
