|1
6128-71-1034
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 26691-.
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 23557-26690
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 20338-23556
1шт.
|1
6128-71-1054
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: 26691-.
1шт.
|1
0
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: 23557-26690
1шт.
|1
0
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: 20338-23556
1шт.
|1
6128-71-1083
INJECTION PUMP ASS'Y,(TBG SPEC.)
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y,(TBG SPEC.)
SN: 26691-.
1шт.
|$$11
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.451 TO 456.
-1шт.
|$$12
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105217-1270
FEED PUMP ASS'Y
SN: 20338-UP
1шт.
1
DK152000-4920
HOUSING ASS'Y
SN: 20338-UP
1шт.
2
DK152010-1120
PISTON
SN: 20338-UP
1шт.
3
DK029620-4000
SEAL
SN: 20338-UP
1шт.
4
DK152111-3220
TAPPET ASS'Y
SN: 20338-UP
1шт.
5
DK152121-0200
RING
SN: 20338-UP
1шт.
6
DK152102-1600
SPRING
SN: 20338-UP
1шт.
7
DK152105-0200
PLUG
SN: 20338-UP
1шт.
8
DK029332-6030
GASKET
SN: 20338-UP
1шт.
9
DK152115-0200
VALVE
SN: 20338-UP
2шт.
10
DK152116-0200
SPRING
SN: 20338-UP
2шт.
11
DK152117-0400
PLUG
SN: 20338-UP
1шт.
12
DK029331-6030
GASKET
SN: 20338-UP
2шт.
13
DK029341-4020
GASKET
SN: 20338-UP
1шт.
14
DK152200-2120
PUMP
SN: 20338-UP
1шт.
15
DK029731-4650
BOLT
SN: 20338-UP
1шт.
16
DK029731-4080
BOLT
SN: 20338-UP
1шт.
17
DK029711-4430
EYE
SN: 20338-UP
1шт.
18
DK029900-6010
PLUG
SN: 20338-UP
1шт.
19
DK029341-4130
GASKET
SN: 20338-UP
4шт.
20
DK152320-0100
COVER
SN: 20338-UP
1шт.
21
DK152215-0520
FILTER
SN: 20338-UP
1шт.
22
DK152220-0100
SPRING
SN: 20338-UP
1шт.
23
DK152350-4400
GASKET
SN: 20338-UP
1шт.
24
DK152222-0400
CASE
SN: 20338-UP
1шт.
25
DK029000-6840
BOLT
SN: 20338-UP
1шт.
26
DK029340-6120
GASKET
SN: 20338-UP
1шт.
|1
6128-71-1034
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 26691-.
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 23557-26690
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 20338-23556
1шт.
|1
6128-71-1054
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: 26691-.
1шт.
|1
0
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: 23557-26690
1шт.
|1
0
INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)
SN: 20338-23556
1шт.
|1
6128-71-1083
INJECTION PUMP ASS'Y,(TBG SPEC.)
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y,(TBG SPEC.)
SN: 26691-.
1шт.
|$$11
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.451 TO 456.
-1шт.
|$$12
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105217-1270
FEED PUMP ASS'Y
SN: 20338-UP
1шт.
1
DK152000-4920
HOUSING ASS'Y
SN: 20338-UP
1шт.
2
DK152010-1120
PISTON
SN: 20338-UP
1шт.
3
DK029620-4000
SEAL
SN: 20338-UP
1шт.
4
DK152111-3220
TAPPET ASS'Y
SN: 20338-UP
1шт.
5
DK152121-0200
RING
SN: 20338-UP
1шт.
6
DK152102-1600
SPRING
SN: 20338-UP
1шт.
7
DK152105-0200
PLUG
SN: 20338-UP
1шт.
8
DK029332-6030
GASKET
SN: 20338-UP
1шт.
9
DK152115-0200
VALVE
SN: 20338-UP
2шт.
10
DK152116-0200
SPRING
SN: 20338-UP
2шт.
11
DK152117-0400
PLUG
SN: 20338-UP
1шт.
12
DK029331-6030
GASKET
SN: 20338-UP
2шт.
13
DK029341-4020
GASKET
SN: 20338-UP
1шт.
14
DK152200-2120
PUMP
SN: 20338-UP
1шт.
15
DK029731-4650
BOLT
SN: 20338-UP
1шт.
16
DK029731-4080
BOLT
SN: 20338-UP
1шт.
17
DK029711-4430
EYE
SN: 20338-UP
1шт.
18
DK029900-6010
PLUG
SN: 20338-UP
1шт.
19
DK029341-4130
GASKET
SN: 20338-UP
4шт.
20
DK152320-0100
COVER
SN: 20338-UP
1шт.
21
DK152215-0520
FILTER
SN: 20338-UP
1шт.
22
DK152220-0100
SPRING
SN: 20338-UP
1шт.
23
DK152350-4400
GASKET
SN: 20338-UP
1шт.
24
DK152222-0400
CASE
SN: 20338-UP
1шт.
25
DK029000-6840
BOLT
SN: 20338-UP
1шт.
26
DK029340-6120
GASKET
SN: 20338-UP
1шт.
