Запчасти Komatsu SA6D155-4A-35 ТОПЛ. НАСОС (/) ТОПЛИВН. СИСТЕМА

|1

6128-71-1034

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 26691-.

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 23557-26690

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 20338-23556

1шт.

|1

6128-71-1054

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: 26691-.

1шт.

|1

0

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: 23557-26690

1шт.

|1

0

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: 20338-23556

1шт.

|1

6128-71-1083

INJECTION PUMP ASS'Y,(TBG SPEC.)

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y,(TBG SPEC.)

SN: 26691-.

1шт.

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.451 TO 456.

-1шт.

|$$12

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105448-9360

GOVERNOR ASS'Y

SN: 26691-UP

1шт.

|1

DK105448-9380

GOVERNOR ASS'Y

SN: 23557-26690

1шт.

|1

DK105448-9310

GOVERNOR ASS'Y

SN: 20338-23556

1шт.

1

DK029310-9080

SHIM

SN: 20338-UP

-2шт.

2

DK029312-0210

SHIM¤ 0.2MM

SN: 20338-UP

-2шт.

|2

DK029312-0180

SHIM¤ 0.5MM

SN: 20338-UP

-2шт.

3

DK154403-4800

SPRING

SN: 20338-UP

1шт.

4

DK154400-4800

ROD

SN: 20338-UP

1шт.

5

DK029330-8050

GASKET

SN: 20338-UP

2шт.

6

DK154352-0700

GASKET

SN: 20338-UP

2шт.

7

DK154400-0520

DIAPHRAGM

SN: 20338-UP

1шт.

8

DK023040-6040

NUT

SN: 20338-UP

2шт.

9

DK154404-3800

COVER

SN: 20338-UP

1шт.

10

DK020106-2240

BOLT

SN: 20338-UP

2шт.

11

DK029010-6310

BOLT

SN: 20338-UP

1шт.

12

DK029320-6010

WASHER

SN: 20338-UP

1шт.

13

DK029731-0120

BOLT

SN: 20338-UP

1шт.

14

DK029341-0110

GASKET

SN: 20338-UP

2шт.

15

DK154404-1100

SCREW

SN: 20338-UP

1шт.

16

DK154035-0320

NUT

SN: 20338-UP

1шт.

17

DK029010-6010

PLUG

SN: 20338-UP

1шт.

18

DK026506-1040

GASKET

SN: 20338-UP

1шт.

|1

6128-71-1034

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 26691-.

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 23557-26690

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 20338-23556

1шт.

|1

6128-71-1054

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: 26691-.

1шт.

|1

0

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: 23557-26690

1шт.

|1

0

INJECTION PUMP ASS'Y,(COLD WEATHER SPEC.)

SN: 20338-23556

1шт.

|1

6128-71-1083

INJECTION PUMP ASS'Y,(TBG SPEC.)

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y,(TBG SPEC.)

SN: 26691-.

1шт.

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.451 TO 456.

-1шт.

|$$12

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105448-9360

GOVERNOR ASS'Y

SN: 26691-UP

1шт.

|1

DK105448-9380

GOVERNOR ASS'Y

SN: 23557-26690

1шт.

|1

DK105448-9310

GOVERNOR ASS'Y

SN: 20338-23556

1шт.

1

DK029310-9080

SHIM

SN: 20338-UP

-2шт.

2

DK029312-0210

SHIM¤ 0.2MM

SN: 20338-UP

-2шт.

|2

DK029312-0180

SHIM¤ 0.5MM

SN: 20338-UP

-2шт.

3

DK154403-4800

SPRING

SN: 20338-UP

1шт.

4

DK154400-4800

ROD

SN: 20338-UP

1шт.

5

DK029330-8050

GASKET

SN: 20338-UP

2шт.

6

DK154352-0700

GASKET

SN: 20338-UP

2шт.

7

DK154400-0520

DIAPHRAGM

SN: 20338-UP

1шт.

8

DK023040-6040

NUT

SN: 20338-UP

2шт.

9

DK154404-3800

COVER

SN: 20338-UP

1шт.

10

DK020106-2240

BOLT

SN: 20338-UP

2шт.

11

DK029010-6310

BOLT

SN: 20338-UP

1шт.

12

DK029320-6010

WASHER

SN: 20338-UP

1шт.

13

DK029731-0120

BOLT

SN: 20338-UP

1шт.

14

DK029341-0110

GASKET

SN: 20338-UP

2шт.

15

DK154404-1100

SCREW

SN: 20338-UP

1шт.

16

DK154035-0320

NUT

SN: 20338-UP

1шт.

17

DK029010-6010

PLUG

SN: 20338-UP

1шт.

18

DK026506-1040

GASKET

SN: 20338-UP

1шт.
