Запчасти Komatsu D32E-1A FIG. E-A ЭЛЕКТР. ЭЛЕКТРОПРОВОДКА - КАБИНА ROPS ЭЛЕКТРИКА
№
Артикул
Название
Примечание
Количество
1
1270 790 H1
CABLE, STARTER TO BATTERY POS
SN: P076093--UP
1шт.
2
1312 866 H91
HARNESS, MAIN ELECTRICAL
SN: P076093--UP
1шт.
3
1306 802 H91
HARNESS, REAR
SN: P076093--UP
1шт.
4
1236 341 H1
DIODE
SN: P076093--UP
1шт.
5
363 660 R1
CLIP, CLOSED
SN: P076093--UP
1шт.
6
363 660 R1
CLIP, CLOSED
SN: P076093--UP
1шт.
7
299 400 C1
CLIP, CLOSED
SN: P076093--UP
1шт.
8
ALTERNATOR (SEE FIG. A6109-A1A1)
SN: P076093--UP
1шт.
|$8
30 003 R1
BOLT, HEX - M8x25
SN: P076093--UP
1шт.
|$9
120 391
WASHER, FLAT - #10
SN: P076093--UP
2шт.
9
MOTOR, STARTING (SEE FIG. A6112-A1A1)
SN: P076093--UP
1шт.
|$11
31 148 R1
BOLT, HEX - M10x30
SN: P076093--UP
2шт.
|$12
1312 025 H91
SWITCHES, FUSES AND RELAYS
SN: P076093--UP
1шт.
10
621 771 C91
SWITCH, NEUTRAL START
SN: P076093--UP
1шт.
|$14
1232 847 H1
WASHER, NEUTRAL START
SN: P076093--UP
1шт.
|$15
177 717 R1
NUT, HEX - 3/4NF
SN: P076093--UP
1шт.
11
1312 854 H91
RELAY, ASSEMBLY
SN: P076093--UP
2шт.
|$17
22 470 R1
BOLT, HEX - 1/4NCx3/4
SN: P076093--UP
2шт.
|$19
120 380
WASHER, LOCK - 1/4
SN: P076093--UP
2шт.
|$20
120 375
NUT, HEX - 1/4NC
SN: P076093--UP
2шт.
|$21
933 833 R1
WASHER, LOCK - M6, TERMINAL
SN: P076093--UP
4шт.
|$22
30 281 R1
NUT, HEX - M6, TERMINAL
SN: P076093--UP
4шт.
12
1311 302 H1
SWITCH, HOURMETER
SN: P076093--UP
1шт.
|$24
417-01-A1630
SEAL, O-RING
SN: P076093--UP
1шт.
14
1308 132 H1
SWITCH, PLASTIC HOUSING
SN: P076093--UP
1шт.
15
1308 427 H1
PLATE, SWITCH HOUSING
SN: P076093--UP
1шт.
|$28
440 502
SCREW, MOUNTING - #10NCx5/8
SN: P076093--UP
2шт.
|$29
120 391
WASHER, FLAT - #10
SN: P076093--UP
2шт.
16
419-43-12260
SWITCH, GEAR INDICATOR
SN: P076093--UP
3шт.
17
1221 297 H2
SWITCH, TRANS. PRESSURE
SN: P076093--UP
1шт.
18
1209 933 H1
ADAPTOR
SN: P076093--UP
1шт.
Выбрано товаров: 33
