Запчасти Komatsu D32E-1A FIG. E-A ГЕНЕРАТОР И ОСНОВН. WIRE Э/ПРОВОДКА ЭЛЕКТРИКА

1

183 039 H1

CABLE, ENGINE TO GROUND

SN: P076093--UP

1шт.

|$1

931 833 R1

BOLT, HEX - M12x25

SN: P076093--UP

1шт.

|$2

25 710 R1

WASHER, FLAT - 1/2

SN: P076093--UP

1шт.

|$3

180 122

BOLT, HEX - 3/8NCx1

SN: P076093--UP

1шт.

|$4

390 305 C1

WASHER, FLAT - 3/8

SN: P076093--UP

1шт.

2

1312 866 H91

HARNESS, MAIN ELECTRICAL

SN: P076093--UP

1шт.

3

1312 865 H1

BRACKET, SUPPORT

SN: P076093--UP

1шт.

|$7

30 041 R1

BOLT, HEX - M12x25

SN: P076093--UP

2шт.

|$8

30 177 R1

WASHER, FLAT - M12

SN: P076093--UP

2шт.

4

301 272 C1

CLIP, CLOSED

SN: P076093--UP

2шт.

|$10

25 222 R1

BOLT, HEX - 1/4NCx3/4

SN: P076093--UP

2шт.

|$11

25 542 R1

WASHER, FLAT - 1/4

SN: P076093--UP

2шт.

5

1306 802 H91

HARNESS, REAR

SN: P076093--UP

1шт.

6

299 566 C1

CLIP, CLOSED

SN: P076093--UP

2шт.

7

299 614 C1

CLIP, CLOSED

SN: P076093--UP

1шт.

|$15

30 041 R1

BOLT, HEX - M12x25

SN: P076093--UP

1шт.

|$16

30 177 R1

WASHER - M12

SN: P076093--UP

1шт.

8

299 615 C1

CLIP, CLOSED

SN: P076093--UP

1шт.

9

850 218 C1

CLIP, CLOSED

SN: P076093--UP

1шт.

10

308 579 C1

CLIP, CLOSED

SN: P076093--UP

3шт.

11

ALTERNATOR (SEE FIG. A6109-A1A1)

SN: P076093--UP

1шт.

|$21

30 003 R1

BOLT, HEX - M8x25

SN: P076093--UP

1шт.

|$22

120 391

WASHER, FLAT - #10

SN: P076093--UP

2шт.

12

1246 021 H1

FAN, ALTERNATOR

SN: P076093--UP

1шт.

13

MOTOR, STARTING (SEE FIG. A6112-A1A1)

SN: P076093--UP

1шт.

|$25

31 148 R1

BOLT, HEX - M10x30

SN: P076093--UP

2шт.

|$26

1312 025 H91

SWITCHES, FUSES AND RELAYS

SN: P076093--UP

1шт.

|$27

1214 890 H2

KEY, DISCONNECT SWITCH ROPS CAB

SN: P076093--UP

2шт.

|$29

OR

-1шт.

|$31

1134 721 C1

KEY, DISCONNECT SWITCH ROPS CANOPY

SN: P076093--UP

2шт.

14

1311 303 H1

SWITCH, ENGINE OIL PRESSURE SENDER

SN: P076093--UP

1шт.

|$33

417-01-A1630

SEAL, O-RING

SN: P076093--UP

1шт.

|$34

120 217

WASHER, LOCK - #10

SN: P076093--UP

1шт.

|$35

120 614

NUT, HEX - #10-32

SN: P076093--UP

1шт.

15

1216 162 H1

SENDER, ENGINE COOLANT TEMPERATURE

SN: P076093--UP

1шт.

16

739 985 C1

SWITCH, AIR CLEANER VACUUM

SN: P076093--UP

1шт.

17

1216 162 H1

SENDER, TRANSMISSION TEMPERATURE

SN: P076093--UP

1шт.

|$39

-1шт.

|$40

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$41

-1шт.
