Запчасти Komatsu D32E-1A FIG. E-A ЭЛЕКТР. ЭЛЕКТРОПРОВОДКА - КАБИНА ROPS ЭЛЕКТРИКА

1

BATTERY (SEE FIG. E0110-01A0)

SN: P076093--UP

1шт.

|$1

1311 350 H91

WIRING AND CLIPS

SN: P076093--UP

1шт.

2

1279 089 H1

CABLE, MASTER SWITCH TO GROUND

SN: P076093--UP

1шт.

|$3

180 120

BOLT, HEX - 3/8NCx3/4

SN: P076093--UP

1шт.

|$4

390 305 C1

WASHER, FLAT - 3/8

SN: P076093--UP

1шт.

3

1270 760 H1

CABLE, MASTER SWITCH TO BATTERY NEG.

SN: P076093--UP

1шт.

4

1270 790 H1

CABLE, STARTER TO BATTERY POS

SN: P076093--UP

1шт.

5

183 039 H1

CABLE, ENGINE TO GROUND

SN: P076093--UP

1шт.

|$8

931 833 R1

BOLT, HEX - M12x25

SN: P076093--UP

1шт.

|$9

25 710 R1

WASHER, FLAT - 1/2

SN: P076093--UP

1шт.

|$10

180 122

BOLT, HEX - 3/8NCx1

SN: P076093--UP

1шт.

|$11

390 305 C1

WASHER - 3/8

SN: P076093--UP

1шт.

6

1312 866 H91

HARNESS, MAIN ELECTRICAL

SN: P076093--UP

1шт.

7

1306 802 H91

HARNESS, REAR

SN: P076093--UP

1шт.

8

299 614 C1

CLIP, CLOSED

SN: P076093--UP

1шт.

|$15

30 041 R1

BOLT, HEX - M12x25

SN: P076093--UP

1шт.

|$16

30 177 R1

WASHER - M12

SN: P076093--UP

1шт.

9

299 400 C1

CLIP, CLOSED

SN: P076093--UP

1шт.

|$18

30 019 R1

BOLT, HEX - M10x20

SN: P076093--UP

1шт.

|$19

30 176 R1

WASHER, FLAT - M10

SN: P076093--UP

1шт.

10

299 400 C1

CLIP, CLOSED

SN: P076093--UP

1шт.

|$21

1270 322 H91

ALTERNATOR AND CRANKING MOTOR

SN: P076093--UP

1шт.

11

ALTERNATOR (SEE FIG. A6109-A1A1)

SN: P076093--UP

1шт.

|$23

30 003 R1

BOLT, HEX - M8x25

SN: P076093--UP

1шт.

|$24

120 391

WASHER, FLAT - #10

SN: P076093--UP

2шт.

12

MOTOR, STARTING (SEE FIG. A6112-A1A1)

SN: P076093--UP

1шт.

|$26

31 148 R1

BOLT, HEX - M10x30

SN: P076093--UP

2шт.

|$27

1312 025 H91

SWITCHES, FUSES AND RELAYS

SN: P076093--UP

1шт.

13

930 587 C4

SWITCH, MASTER DISCONNECT

SN: P076093--UP

1шт.

|$29

1134 721 C1

KEY, DISCONNECT SWITCH

SN: P076093--UP

2шт.

14

1312 854 H91

RELAY, ASSEMBLY

SN: P076093--UP

2шт.

|$31

22 470 R1

BOLT, HEX - 1/4NCx3/4

SN: P076093--UP

2шт.

|$32

120 392

WASHER, FLAT - 1/4

SN: P076093--UP

2шт.

|$33

120 380

WASHER, LOCK - 1/4

SN: P076093--UP

2шт.

|$34

120 375

NUT, HEX - 1/4NC

SN: P076093--UP

2шт.

|$35

933 833 R1

WASHER, LOCK - M6TERMINAL

SN: P076093--UP

4шт.

|$36

30 281 R1

NUT, HEX - M6TERMINAL

SN: P076093--UP

4шт.

15

1216 162 H1

SENDER, ENGINE COOLANT TEMPERATURE.

SN: P076093--UP

1шт.

16

627 670 C1

SWITCH, WARNING HORN

SN: P076093--UP

1шт.

|$40

OR

-1шт.

|$42

453 453 C1

SWITCH, WARNING HORN

SN: P076093--UP

1шт.

|$43

1270 270 H91

WARNING HORN

SN: P076093--UP

1шт.

17

1313 809 H1

HORN, WARNING

SN: P076093--UP

1шт.

|$45

30 002 R1

BOLT, HEX - M8x20

SN: P076093--UP

1шт.

|$46

134 309 R1

WASHER, LOCK - M8

SN: P076093--UP

1шт.

|$47

-1шт.

|$48

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$49

-1шт.
