Запчасти Komatsu D32E-1A FIG. E-A АККУМУЛЯТОР И КРЕПЛЕНИЕ - КАБИНА ROPS ЭЛЕКТРИКА

|$0

1304 493 H92

BOX ASSEMBLY, BATTERY

SN: P076093--UP

1шт.

1

NSS

BOX, BATTERY

SN: P076093--UP

1шт.

2

1302 358 H1

SEAL, TOP AND BOTTOM DOOR

SN: P076093--UP

2шт.

3

1286 678 H1

SEAL, SIDE DOOR

SN: P076093--UP

2шт.

|$4

24 875 R1

BOLT, HEX - 5/8NCx2

SN: P076093--UP

4шт.

|$5

25 547 R1

WASHER, FLAT - 5/8

SN: P076093--UP

4шт.

4

1299 603 H1

SHIM, BATTERY BOX

SN: P076093--UP

-2шт.

|$7

1299 596 H91

DOOR ASSEMBLY, BATTERY BOX

SN: P076093--UP

1шт.

5

NSS

DOOR, BATTERY BOX

SN: P076093--UP

1шт.

6

1297 517 H91

LATCH, DOOR

SN: P076093--UP

1шт.

|$10

104 066

RIVET, BUTTON HEAD - 3/16x3/8

SN: P076093--UP

4шт.

|$11

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P076093--UP

2шт.

|$12

25 534 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$13

650 382 C92

PADLOCK WITH KEYS

SN: P076093--UP

1шт.

|$14

1311 216 H1

KEY, REPLACEMENT

SN: P076093--UP

1шт.

7

TRIM, FRONT INNER - 28IN LONG

SN: P076093--UP

1шт.

8

TRIM, MIDDLE INNER - 6IN LONG

SN: P076093--UP

1шт.

9

TRIM, REAR INNER - 8IN LONG

SN: P076093--UP

1шт.

10

739 948 C1

BAR, HOLD DOWN

SN: P076093--UP

1шт.

|$19

28 246 R1

BOLT, HEX - 3/8NCx10

SN: P076093--UP

2шт.

|$20

25 544 R1

WASHER, FLAT - 3/4

SN: P076093--UP

2шт.

11

1298 876 H91

STRIKER, DOOR

SN: P076093--UP

1шт.

|$22

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P076093--UP

2шт.

|$23

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

12

1302 399 H1

PAD, FOAM RUBBER

SN: P076093--UP

1шт.

13

PLATE, SAFETY LEVER(SEE FIG. K0710-01A0)

SN: P076093--UP

1шт.

14

1308 809 H1

LINK

SN: P076093--UP

1шт.

|$27

20 791 R1

PIN, CLEVIS - 1/4x29/32

SN: P076093--UP

1шт.

|$28

22 256 R1

WASHER, FLAT - 9/32

SN: P076093--UP

1шт.

|$29

103 361

PIN, COTTER - 1/16x1/2

SN: P076093--UP

1шт.

15

1302 398 H1

SPRING

SN: P076093--UP

1шт.

|$31

23 840 R1

PIN, CLEVIS - 5/16x1-3/16

SN: P076093--UP

1шт.

|$32

120 393

WASHER, FLAT - 5/16

SN: P076093--UP

2шт.

|$33

119 117

PIN, COTTER - 3/32x1/2

SN: P076093--UP

1шт.

|$34

1270 274 H91

WARM START BATTERY

SN: P076093--UP

1шт.

16

1269 028 H1

BATTERY

SN: P076093--UP

1шт.

|$37

OR

-1шт.

|$39

1269 029 H1

BATTERY

SN: P076093--UP

1шт.

|$40

476 074 C1

NUT, TERMINAL - 3/8NC

SN: P076093--UP

2шт.

|$41

1270 275 H91

COLD START BATTERY

SN: P076093--UP

1шт.

|$42

1262 660 H1

TRIM, BULK EDGE

SN: P076093--UP

-2шт.

|$43

-1шт.

|$44

F1 - CUT REQUIRED LENGTH FROM BULK EDGE TRIM 1262 660 H1.

-1шт.

|$45

-1шт.

|$46

-1шт.

|$47

F2 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$48

-1шт.
