Запчасти Komatsu D32E-1A FIG. A9-AA ГЕНЕРАТОР ДВИГАТЕЛЬ

|$0

1302 375 H91

ALTERNATOR ASSEMBLY

1шт.

1

124 934

NUT, LOCK

1шт.

2

1250 497 H1

WASHER, LOCK

1шт.

3

1303 792 H1

SPACER, FAN

1шт.

4

1303 793 H1

HOUSING, FRONT

1шт.

5

1303 794 H1

BEARING, FRONT

1шт.

6

1303 795 H1

RETAINER, FRONT BEARING

1шт.

7

1303 791 H1

BOLT, HEX (#10NCx3-5/16)

4шт.

8

1303 796 H1

ROTOR

1шт.

9

NSS

BEARING, REAR

1шт.

10

1303 798 H1

STATOR

1шт.

11

1303 797 H1

RETAINER, REAR BEARING

1шт.

12

1250 448 H1

CAPACITOR

1шт.

13

NSS

TRIO, DIODE

1шт.

|$14

NSS

SCREW, MOUNTING

4шт.

14

1303 799 H1

DIODE, POSITIVE RECTIFIER

1шт.

|$16

1303 807 H1

NUT, LOCK (M5)

1шт.

15

1303 806 H1

TERMINAL, RING

1шт.

16

1303 800 H1

DIODE, NEGATIVE RECTIFIER

1шт.

17

NSS

INSULATOR

2шт.

18

1303 802 H1

INSULATOR

4шт.

19

1303 805 H1

METAL, FLAT

2шт.

20

1303 809 H1

METAL, FLAT

1шт.

21

1303 801 H1

HOUSING, REAR

1шт.

22

1303 790 H1

REGULATOR, VOLTAGE

1шт.

|$25

NSS

SCREW, MOUNTING (#8NCx1/2)

2шт.

23

1303 789 H1

BRUSH ASSEMBLY

1шт.

|$27

NSS

SCREW, MOUNTING (#8NCx1/2)

2шт.

24

1303 808 H1

INSULATOR, SLEEVE (1/4x1/2)

1шт.

25

1303 803 H1

INSULATOR, SLEEVE (#10x1/3)

1шт.

26

1303 804 H1

INSULATOR, SLEEVE

1шт.

27

1303 807 H1

NUT, LOCK (M5x1/8)

5шт.

28

FAN, ALTERNATOR (SEE FIG. E0200-01A1)

1шт.

29

PULLEY, ALTERNATOR (SEE FIG. A6103-A1A1)

SN: UP

1шт.
