Запчасти Komatsu D32E-1A FIG. R-A LUBRICATED ГУСЕНИЦЫ СИСТЕМА - DP-A - MULTIPLE NOTCH SPLIT СОЕДИНИТЕЛЬН. ЗВЕНО ХОДОВАЯ

|$0

1301 629 H91

CHAIN ASSEMBLY, TRACK

SN: P076093--UP

2шт.

|$1

1301 328 H91

LINK ASSEMBLY, LEFT MASTER

SN: P076093--UP

1шт.

1

NSS

LINK, LEFT MASTER - PIN END

SN: P076093--UP

1шт.

2

NSS

LINK, LEFT MASTER - BUSHING END

SN: P076093--UP

1шт.

|$4

1301 325 H1

BOLT, MASTER LINK TRACK SHOE

SN: P076093--UP

2шт.

|$5

1301 329 H91

LINK ASSEMBLY, RIGHT MASTER

SN: P076093--UP

1шт.

3

NSS

LINK, RIGHT MASTER - PIN END

SN: P076093--UP

1шт.

4

NSS

LINK, RIGHT MASTER - BUSHING END

SN: P076093--UP

1шт.

|$8

1301 325 H1

BOLT, MASTER LINK TRACK SHOE

SN: P076093--UP

2шт.

5

1237 191 H1

BUSHING, CHAIN LINK

SN: P076093--UP

37шт.

6

1237 193 H1

PIN, CHAIN LINK

SN: P076093--UP

37шт.

7

1237 196 H1

WASHER, THRUST

SN: P076093--UP

74шт.

8

1236 891 H1

LINK, RIGHT CHAIN

SN: P076093--UP

36шт.

9

1236 890 H1

LINK, LEFT CHAIN

SN: P076093--UP

36шт.

10

1301 327 H91

PLUG, PIN

SN: P076093--UP

37шт.

11

1301 326 H91

SEAL, CHAIN

SN: P076093--UP

74шт.

|$16

1301 325 H1

BOLT, MASTER LINK TRACK SHOE LONG

SN: P076093--UP

2шт.

|$17

1301 335 H1

BOLT, MASTER LINK TRACK SHOE SHORT

SN: P076093--UP

2шт.
