Запчасти Komatsu D32E-1A FIG. R-A LUBRICATED ГУСЕНИЦЫ СИСТЕМА - DE-A - ОДИНОЧН. NOTCH SPLIT СОЕДИНИТЕЛЬН. ЗВЕНО ХОДОВАЯ
№
Артикул
Название
Примечание
Количество
|$0
1306 623 H91
LUBRICATED TRACK SYSTEM
SN: P076093--UP
1шт.
|$1
1237 164 H93
CHAIN ASSEMBLY, TRACK
SN: P076093--UP
2шт.
1
1236 887 H1
LINK, RIGHT MASTER - PIN END
SN: P076093--UP
1шт.
2
1236 886 H1
LINK, LEFT MASTER - PIN END
SN: P076093--UP
1шт.
3
1237 191 H1
BUSHING, CHAIN LINK
SN: P076093--UP
34шт.
4
1237 193 H1
PIN, CHAIN LINK
SN: P076093--UP
34шт.
5
1237 196 H1
WASHER, THRUST
SN: P076093--UP
68шт.
6
1236 891 H1
LINK, RIGHT CHAIN
SN: P076093--UP
33шт.
7
1236 890 H1
LINK, LEFT CHAIN
SN: P076093--UP
33шт.
8
1236 888 H1
LINK, LEFT MASTER - BUSHING END
SN: P076093--UP
1шт.
9
1236 889 H1
LINK, RIGHT MASTER - BUSHING END
SN: P076093--UP
1шт.
10
739 158 C1
PLUG, PIN
SN: P076093--UP
34шт.
11
1252 955 H91
SEAL, CHAIN
SN: P076093--UP
68шт.
|$13
1236 990 H2
BOLT, MASTER LINK TRACK SHOE
SN: P076093--UP
4шт.
|$14
1237 162 H93
CHAIN WITH 15IN SHOES
SN: P076093--UP
2шт.
|$15
CHAIN, TRACK - SEE ABOVE
SN: P076093--UP
1шт.
|$16
SHOE, TRACK (SEE FIG. R0500-01A0)
SN: P076093--UP
34шт.
|$17
616 199 C4
BOLT, TRACK SHOE
SN: P076093--UP
132шт.
|$18
616 200 C1
NUT, SHOE BOLT
SN: P076093--UP
132шт.
|$19
1237 159 H93
CHAIN WITH 15IN SHOES - MUD RELIEF
SN: P076093--UP
2шт.
|$20
CHAIN, TRACK - SEE ABOVE
SN: P076093--UP
1шт.
|$21
SHOE, TRACK (SEE FIG. R0500-01A0)
SN: P076093--UP
34шт.
|$22
616 199 C4
BOLT, TRACK SHOE
SN: P076093--UP
132шт.
|$23
616 200 C1
NUT, SHOE BOLT
SN: P076093--UP
132шт.
|$24
1270 589 H91
CHAIN WITH 17IN SHOES
SN: P076093--UP
2шт.
|$25
CHAIN, TRACK - SEE ABOVE
SN: P076093--UP
1шт.
|$26
SHOE, TRACK (SEE FIG. R0500-01A1)
SN: P076093--UP
34шт.
|$27
616 199 C4
BOLT, TRACK SHOE
SN: P076093--UP
132шт.
|$28
616 200 C1
NUT, SHOE BOLT
SN: P076093--UP
132шт.
|$29
-1шт.
|$30
F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.
-1шт.
|$31
-1шт.
