Запчасти Komatsu D32E-1A FIG. R-A ГУСЕНИЦЫS - DP-A, D8P-A ХОДОВАЯ

|$0

1281 168 H91

TRACK SHOES, 24 IN

SN: P076093--UP

1шт.

1

1236 987 H1

SHOE, TRACK

SN: P076093--UP

74шт.

2

616 199 C4

BOLT, TRACK SHOE

SN: P076093--UP

288шт.

3

616 200 C1

NUT, TRACK SHOE

SN: P076093--UP

288шт.

4

1258 970 H91

BAR, C-FRAME RUB

SN: P076093--UP

2шт.

|$5

24 876 R1

BOLT, HEX - 5/8NCx2-1/4

SN: P076093--UP

8шт.

|$6

25 547 R1

WASHER, FLAT - 5/8

SN: P076093--UP

8шт.

5

1271 387 R1

PLATE, RUB BAR

SN: P076093--UP

2шт.

6

1258 997 H1

SHIM, RUB BAR

SN: P076093--UP

-2шт.

7

BOLT, MASTER LINK (SEE FIG. R0500-02A2)

SN: P076093--UP

8шт.

|$10

-1шт.

|$11

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$12

-1шт.
