Запчасти Komatsu D32E-1A FIG. R-A ГУСЕНИЦЫS - DE-A ХОДОВАЯ

|$0

1237 777 H91

TRACK SHOES

SN: P076093--UP

1шт.

1

1236 985 H1

SHOE, TRACK

SN: P076093--UP

68шт.

2

616 199 C4

BOLT, TRACK SHOE

SN: P076093--UP

264шт.

3

616 200 C1

NUT, TRACK SHOE

SN: P076093--UP

264шт.

4

BOLT, MASTER LINK (SEE FIG. R0500-02A0)

SN: P076093--UP

8шт.

|$5

1237 778 H91

TRACK SHOE, MUD RELIEF

SN: P076093--UP

1шт.

5

1237 418 H1

SHOE, TRACK

SN: P076093--UP

68шт.

6

616 199 C4

BOLT, TRACK SHOE

SN: P076093--UP

264шт.

7

616 200 C1

NUT, TRACK SHOE

SN: P076093--UP

264шт.

8

BOLT, MASTER LINK (SEE FIG. R0500-02A0)

SN: P076093--UP

4шт.

|$10

-1шт.

|$11

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$12

-1шт.
