Запчасти Komatsu D32E-1A FIG. R-A ГУСЕНИЦЫ РЕГУЛЯТОР ХОДОВАЯ

1

736 160 C2

FORK, FRONT IDLER - CAST

SN: P076093--UP

2шт.

|$2

OR

-1шт.

|$4

1299 268 H91

FORK, FRONT IDLER - WELDED

SN: P076093--UP

2шт.

|$5

24 863 R1

BOLT, HEX 1/2NCx13/4

SN: P076093--UP

8шт.

|$6

116 121

WASHER, LOCK 1/2

SN: P076093--UP

8шт.

2

319 628 R91

VALVE, ADJUSTER CHECK

SN: P076093--UP

2шт.

3

109 461

FITTING, LUBE

SN: P076093--UP

2шт.

4

662 799 C1

PLUG, ADJUSTER BLEEDER

SN: P076093--UP

2шт.

5

621 430 C1

SHIELD, ADJUSTER

SN: P076093--UP

2шт.

|$11

24 862 R1

BOLT, HEX 1/2NCx1-1/2

SN: P076093--UP

4шт.

|$12

116 121

WASHER, LOCK 1/2

SN: P076093--UP

4шт.

|$13

622 825 C91

KIT, PISTON SEAL

SN: P076093--UP

2шт.

6

NSS

WIPER, ROD

SN: P076093--UP

1шт.

7

NSS

RING, PISTON

SN: P076093--UP

1шт.

8

622 049 C1

PISTON, ADJUSTER

SN: P076093--UP

2шт.

9

621 448 C4

ROD, TRACK ADJUSTER, (E MODEL)

SN: P076093--UP

2шт.

|$19

OR

-1шт.

|$21

1281 972 H1

ROD, TRACK ADJUSTER, (P MODEL)

SN: P076093--UP

2шт.

10

NSS

RETAINER, TRACK SPRING

SN: P076093--UP

4шт.

11

NSS

SPRING, TRACK

SN: P076093--UP

2шт.

12

1280 545 H1

PLATE, SCRAPER

SN: P076093--UP

2шт.

|$25

-1шт.

|$26

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.
