Запчасти Komatsu D32E-1A FIG. K-A ТРАНСМИССИЯ/РУЛЕВ. УПРАВЛЕНИЕ УПРАВЛ-ЕS - С СИСТЕМОЙ ROPS КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1308 340 H91

VALVES AND CONTROLS.

SN: P076093--UP

1шт.

1

VALVE, TRANS/STEER CONTROL(SEE FIG. F2300-09A0)

SN: P076093--UP

1шт.

|$2

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P076093--UP

3шт.

|$3

25 534 R1

WASHER, FLAT - 3/8

SN: P076093--UP

3шт.

2

17A-43-25681

KNOB, CONTROL

SN: P076093--UP

1шт.

3

20T-43-71190

NUT, JAM

SN: P076093--UP

1шт.

4

1308 473 H91

HANDLE, FEATHERING

SN: P076093--UP

1шт.

|$7

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P076093--UP

4шт.

|$8

25 534 R1

WASHER, FLAT - 3/8

SN: P076093--UP

4шт.

5

14X-43-11320

BOOT, CONTROL HANDLE

SN: P076093--UP

1шт.

6

1308 476 H91

RETAINER, BOOT

SN: P076093--UP

1шт.

|$11

25 485 R1

BOLT, HEX - 1/4NCx1-1/4

SN: P076093--UP

4шт.

|$12

25 532 R1

WASHER, FLAT - 1/4

SN: P076093--UP

4шт.

7

1309 014 H1

PLATE, BOOT RETAINER

SN: P076093--UP

1шт.

8

LEVER, SAFETY (SEE FIG. K2400-02A0)

SN: P076093--UP

1шт.

|$15

25 483 R1

BOLT, HEX - 1/4NCx1

SN: P076093--UP

1шт.

|$16

25 532 R1

WASHER, FLAT - 1/4

SN: P076093--UP

1шт.

9

1308 484 H1

GROMMET

SN: P076093--UP

1шт.

10

1309 018 H1

COLLAR

SN: P076093--UP

1шт.

|$19

350 684 R1

RING, SEAL

SN: P076093--UP

1шт.

11

BOX, BATTERY (SEE FIG. E0110-01A0)

SN: P076093--UP

1шт.

|$21

-1шт.

|$22

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$23

-1шт.
