Запчасти Komatsu D32E-1A FIG. K-A КРЫЛОS И ПЛАТФОРМАS - КАБИНА ROPS КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1300 486 H91

FENDERS AND PLATFORMS

SN: P076093--UP

1шт.

|$1

1300 612 H91

PLATE ASSEMBLY, FLOOR

SN: P076093--UP

1шт.

1

1300 613 H91

PLATE, FLOOR

SN: P076093--UP

1шт.

|$3

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P076093--UP

4шт.

|$4

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

4шт.

2

1300 614 H1

LINING, SOUND INSULATION

SN: P076093--UP

1шт.

3

1171 134 C2

FASTENER

SN: P076093--UP

5шт.

4

1299 607 H91

FENDER, LEFT

SN: P076093--UP

1шт.

|$8

24 891 R1

BOLT, HEX - 3/4NCx2-3/4

SN: P076093--UP

4шт.

|$9

25 548 R1

WASHER, FLAT - 3/4

SN: P076093--UP

4шт.

5

1299 608 H91

FENDER, RIGHT

SN: P076093--UP

1шт.

|$11

24 891 R1

BOLT, HEX - 3/4NCx2-3/4

SN: P076093--UP

4шт.

|$12

25 548 R1

WASHER, FLAT - 3/4

SN: P076093--UP

4шт.

6

CAB, ROPS (SEE FIG. K0210-01A0)

SN: P076093--UP

1шт.

7

BRACKET, RIGHT MTNG(SEE FIG. K0210-01A0)

SN: P076093--UP

1шт.

8

BRACKET, LEFT MTNG(SEE FIG. K0210-01A0)

SN: P076093--UP

1шт.

|$16

-1шт.

|$17

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$18

-1шт.
