Запчасти Komatsu D32E-1A FIG. K-A КАБИНА ROPS - ЛЕВ. ENTRY ДВЕРЬ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

CAB ASSEMBLY, COMPLETE(SEE FIG. K0210-03A0)

SN: P076093--UP

1шт.

1

1304 402 H1

GLASS, DOOR

SN: P076093--UP

1шт.

2

SEAL, DOOR GLASS - 132.5IN LONG

SN: P076093--UP

1шт.

|$3

1304 304 H91

DOOR ASSEMBLY, LEFT ENTRY

SN: P076093--UP

1шт.

3

NSS

DOOR, ENTRY

SN: P076093--UP

1шт.

4

273 355

FITTING, LUBE

SN: P076093--UP

1шт.

5

LINKAGE, DOOR (SEE FIG. K0210-03A11)

SN: P076093--UP

1шт.

6

1300 535 H1

COVER, LATCH

SN: P076093--UP

1шт.

|$8

931 828 R1

BOLT, HEX - M6x20

SN: P076093--UP

4шт.

|$9

30 325 R1

WASHER, FLAT - M6

SN: P076093--UP

4шт.

7

1304 244 H1

GUARD, LINKAGE

SN: P076093--UP

1шт.

|$11

931 828 R1

BOLT, HEX - M6x20

SN: P076093--UP

4шт.

|$12

30 325 R1

WASHER, FLAT - M6

SN: P076093--UP

4шт.

8

1300 551 H1

BLOCK, LOCK PLATE

SN: P076093--UP

1шт.

9

1300 552 H1

PLATE, LOCK

SN: P076093--UP

1шт.

|$15

30 026 R1

BOLT, HEX - M10x55

SN: P076093--UP

2шт.

|$16

30 176 R1

WASHER, FLAT - M10

SN: P076093--UP

2шт.

10

MOTOR, WIPER (SEE FIG. K0210-05A1)

SN: P076093--UP

1шт.

11

1309 335 H1

GUARD, WIPER MOTOR

SN: P076093--UP

1шт.

|$19

31 006 R1

SCREW, PAN HEAD - M6x16

SN: P076093--UP

4шт.

|$20

934 948 C1

WASHER, FLAT - M6

SN: P076093--UP

4шт.

|$21

1301 319 H1

SEAL, BULK WINDOW

SN: P076093--UP

-2шт.

|$22

-1шт.

|$23

F1 - CUT REQUIRED LENGTH FROM BULK WINDOW SEAL 1301 319 H1

-1шт.

|$24

-1шт.
