Запчасти Komatsu D32E-1A FIG. K-A КАБИНА ROPS - ЗАДН. ОКНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

CAB ASSEMBLY, COMPLETE(SEE FIG. K0210-03A0)

SN: P076093--UP

1шт.

|$1

1304 351 H91

WINDOW ASSEMBLY, REAR

SN: P076093--UP

1шт.

1

1304 354 H91

FRAME, WINDOW

SN: P076093--UP

1шт.

2

1304 378 H1

GLASS, STATIONERY

SN: P076093--UP

1шт.

3

1300 570 H1

SEAL, GLASS

SN: P076093--UP

1шт.

4

1309 941 H1

BLOCK, STOP

SN: P076093--UP

2шт.

|$6

1309 918 H1

SCREW - M4x16

SN: P076093--UP

2шт.

5

1300 563 H1

FRAME, GLASS

SN: P076093--UP

1шт.

6

1300 574 H1

SEAL, FRAME

SN: P076093--UP

1шт.

7

1300 577 H1

SEAL, GLASS

SN: P076093--UP

1шт.

8

1300 567 H1

BRACKET, KEEPER

SN: P076093--UP

2шт.

|$11

1309 946 H1

SCREW - M5x14

SN: P076093--UP

2шт.

9

1300 568 H1

FASTENER, FRAME

SN: P076093--UP

1шт.

|$13

1309 946 H1

SCREW - M5x14

SN: P076093--UP

4шт.

10

1300 572 H1

SEAL, INNER FRAME TRACT

SN: P076093--UP

1шт.

|$15

1304 380 H91

LATCH ASSEMBLY, WINDOW

SN: P076093--UP

1шт.

11

1304 381 H1

GASKET, LATCH

SN: P076093--UP

1шт.

12

1309 242 H1

LOCK, WINDOW

SN: P076093--UP

1шт.

13

1309 243 H1

PLATE, MOUNTING

SN: P076093--UP

1шт.

|$19

31 143 R1

SCREW - M4x50

SN: P076093--UP

2шт.

14

1304 379 H1

GLASS, SLIDING

SN: P076093--UP

1шт.
