Запчасти Komatsu D32E-1A FIG. K-A КАБИНА ROPS - COMPLETE ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1304 301 H91

CAB ASSEMBLY, COMPLETE

SN: P076093--UP

1шт.

|$1

HEADLINER, COVERS AND INSULATION(SEE FIG. K0210-03A1)

SN: P076093--UP

1шт.

|$2

SIDE COVERS AND INSULATION(SEE FIG. K0210-03A2)

SN: P076093--UP

1шт.

1

NSS

CAB, WELDMENT

SN: P076093--UP

1шт.

2

1304 443 H1

SEAL, DOOR

SN: P076093--UP

2шт.

3

SEAL, REAR WINDOW - 130 IN LONG

SN: P076093--UP

1шт.

4

WINDOW, REAR (SEE FIG. K0210-03A4)

SN: P076093--UP

1шт.

|$7

1299 664 H92

COVER ASSEMBLY, FILTER ACCESS

SN: P076093--UP

1шт.

5

NSS

COVER, ACCESS

SN: P076093--UP

1шт.

6

1309 502 H1

GASKET, COVER

SN: P076093--UP

1шт.

|$10

931 827 R1

BOLT, HEX - M6x16

SN: P076093--UP

4шт.

|$11

30 325 R1

WASHER, FLAT - M6

SN: P076093--UP

4шт.

|$12

30 694 R1

SCREW, LATCH - M5x16

SN: P076093--UP

4шт.

7

1300 606 H1

BUSHING, THREADED

SN: P076093--UP

4шт.

8

SEAL, SIDE WINDOW - 120 IN LONG

SN: P076093--UP

2шт.

9

WINDOW, RIGHT (SEE FIG. K0210-03A5)

SN: P076093--UP

1шт.

10

WINDOW, LEFT (SEE FIG. K0210-03A6)

SN: P076093--UP

1шт.

11

LATCH, DOOR (SEE FIG. K0210-03A7)

SN: P076093--UP

1шт.

|$18

30 020 R1

BOLT, HEX - M10x25

SN: P076093--UP

2шт.

|$19

30 176 R1

WASHER, FLAT - M10

SN: P076093--UP

2шт.

12

LATCH, DOOR (SEE FIG. K0210-03A7)

SN: P076093--UP

1шт.

|$21

30 020 R1

BOLT, HEX - M10x25

SN: P076093--UP

2шт.

|$22

30 176 R1

WASHER, FLAT - M10

SN: P076093--UP

2шт.

13

1304 188 H1

GASKET, REAR SIDE LOWER

SN: P076093--UP

2шт.

14

1304 187 H1

GASKET, REAR SIDE UPPER

SN: P076093--UP

2шт.

15

1300 608 H2

GASKET, RIGHT DOOR REAR

SN: P076093--UP

1шт.

16

1300 609 H2

GASKET, LEFT DOOR REAR

SN: P076093--UP

1шт.

17

1300 610 H2

GASKET, RIGHT DOOR FRONT

SN: P076093--UP

1шт.

18

1300 611 H2

GASKET, LEFT DOOR FRONT

SN: P076093--UP

1шт.

19

DOOR, RIGHT (SEE FIG. K0210-03A8)

SN: P076093--UP

1шт.

|$30

30 021 R1

BOLT, HEX - M10x30

SN: P076093--UP

4шт.

|$31

30 184 R1

WASHER, FLAT - M10

SN: P076093--UP

4шт.

20

DOOR, LEFT (SEE FIG. K0210-03A10)

SN: P076093--UP

1шт.

|$33

30 021 R1

BOLT, HEX - M10x30

SN: P076093--UP

4шт.

|$34

30 184 R1

WASHER, FLAT - M10

SN: P076093--UP

4шт.

21

1304 405 H1

GLASS, FRONT

SN: P076093--UP

1шт.

22

SEAL, FRONT GLASS - 90IN LONG

SN: P076093--UP

1шт.

23

TRIM, EDGE - 30IN LONG

SN: P076093--UP

2шт.

|$38

1301 319 H1

SEAL, BULK WINDOW

SN: P076093--UP

-2шт.

|$39

1262 660 H1

TRIM, BULK EDGE

SN: P076093--UP

-2шт.

|$46

-1шт.

|$40

-1шт.

|$41

F1 - CUT REQUIRED LENGTH FROM BULK WINDOW SEAL 1301 319 H1.

-1шт.

|$43

-1шт.

|$44

F2 - CUT REQUIRED LENGTH FROM BULK EDGE TRIM 1262 660 H1.

-1шт.

|$45

-1шт.
