Запчасти Komatsu D32E-1A FIG. J-A РАМА И СОЕДИН-ЕS - DE-A ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$0

1306 388 H91

FRAME

SN: P076093--UP

1шт.

|$1

1306 389 H92

FRAME ASSEMBLY, FRONT

SN: P076093--UP

1шт.

1

NSS

FRAME

SN: P076093--UP

1шт.

2

NSS

CAP, MOUNTING

SN: P076093--UP

2шт.

|$4

26 720 R1

BOLT, HEX - 1NCx5

SN: P076093--UP

4шт.

|$5

25 540 R1

WASHER, FLAT - 1

SN: P076093--UP

4шт.

|$6

26 117 R1

BOLT, HEX - 7/8NCx4-1/4

SN: P076093--UP

6шт.

|$7

25 910 R1

BOLT, HEX - 7/8NCx3-1/4

SN: P076093--UP

2шт.

|$8

25 761 R1

BOLT, HEX - 7/8NCx5

SN: P076093--UP

2шт.

|$9

622 015 C1

BOLT, SAFETY - 7/8NCx5

SN: P076093--UP

2шт.

|$10

25 530 R1

NUT, HEX - 7/8NC

SN: P076093--UP

2шт.

|$11

277 606 R1

WASHER, FLAT - 29/64

SN: P076093--UP

10шт.

3

1261 705 H1

BAR, TIE

SN: P076093--UP

2шт.

|$13

341 811 R1

WASHER, FLAT

SN: P076093--UP

2шт.

|$14

25 762 R1

NUT, HEX - 1-1/8NC

SN: P076093--UP

2шт.

4

1262 805 H1

SHIM, MOUNTING - 0.060IN

SN: P076093--UP

-2шт.

|$16

1262 806 H1

SHIM, MOUNTING - 0.030IN

SN: P076093--UP

-2шт.

|$17

1262 807 H1

SHIM, MOUNTING - 0.015IN

SN: P076093--UP

-2шт.

5

620 862 C1

SPACER, TIE BAR

SN: P076093--UP

2шт.

6

308 872 R1

CLIP, CLOSED

SN: P076093--UP

1шт.

|$20

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P076093--UP

1шт.

|$21

25 544 R1

WASHER, FLAT - 3/8

SN: P076093--UP

1шт.

7

FRAME, REAR (SEE FIG. J2110-01A0)

SN: P076093--UP

1шт.

8

717 260 C1

GASKET WITH SPACERS, COVER

SN: P076093--UP

1шт.

9

1306 726 H1

COVER, REAR FRAME

SN: P076093--UP

1шт.

|$25

24 841 R1

BOLT, HEX - 3/8NCx1-1/2

SN: P076093--UP

25шт.

|$26

25 534 R1

WASHER, FLAT - 3/8

SN: P076093--UP

25шт.

10

1281 074 H91

TUBE, UPPER FILLER

SN: P076093--UP

1шт.

11

1281 072 H91

TUBE, LOWER FILLER

SN: P076093--UP

1шт.

12

1281 725 H1

DIPSTICK

SN: P076093--UP

1шт.

13

733 040 C2

PLATE, PTO COVER

SN: P076093--UP

1шт.

|$31

26 957 R1

BOLT, HEX - 5/8NCx1

SN: P076093--UP

6шт.

|$32

259 190 R1

O-RING, COVER

SN: P076093--UP

1шт.

14

621 575 C1

STIFFENER, SIDE

SN: P076093--UP

2шт.

15

621 576 C1

STIFFENER, FRONT OR BACK

SN: P076093--UP

2шт.

16

662 250 C1

BREATHER, REAR FRAME

SN: P076093--UP

1шт.

|$37

OR

-1шт.

|$39

666 156 C1

BREATHER, REAR FRAME

SN: P076093--UP

1шт.

17

105 407

NIPPLE, PIPE

SN: P076093--UP

1шт.

18

105 413

ELBOW - 90°

SN: P076093--UP

1шт.

19

706 443 C2

BAFFLE, REAR FRAME SUMP

SN: P076093--UP

1шт.

|$43

27 879 R1

BOLT, HEX - 1/2NCx3/4

SN: P076093--UP

2шт.

|$44

25 536 R1

WASHER, FLAT - 1/2

SN: P076093--UP

2шт.

20

1268 300 H1

BEARING, NON-LUBE

SN: P076093--UP

2шт.

21

1268 301 H1

SEAL, PIN

SN: P076093--UP

4шт.

22

1284 563 H1

LINK, RADIATOR

SN: P076093--UP

1шт.

|$48

140 483 H

BOLT, HEX - 3/8NCx1-1/4

SN: P076093--UP

2шт.

|$49

178 372 R1

WASHER, FLAT - 13/32

SN: P076093--UP

4шт.

23

625 875 C1

MOUNT, SHOCK

SN: P076093--UP

2шт.

24

1262 270 H1

PLATE, SPACER

SN: P076093--UP

2шт.

|$52

1308 331 H91

DOOR, RADIATOR GUARD

SN: P076093--UP

1шт.

25

1306 806 H1

DOOR, RADIATOR

SN: P076093--UP

1шт.

|$54

26 318 R1

BOLT, HEX - 1/2NCx1-1/2

SN: P076093--UP

6шт.

|$55

25 546 R1

WASHER, FLAT - 1/2

SN: P076093--UP

6шт.

|$56

1312 965 H91

DOOR, HEAVY DUTY RADIATOR GUARD

SN: P076093--UP

1шт.

26

1312 852 H91

DOOR, RADIATOR

SN: P076093--UP

1шт.

|$58

26 318 R1

BOLT, HEX - 1/2NCx1-1/2

SN: P076093--UP

6шт.

|$59

25 546 R1

WASHER, FLAT - 1/2

SN: P076093--UP

6шт.

|$60

1312 952 H1

PLATE, DOOR HINGE

SN: P076093--UP

2шт.

|$61

1315 038 H1

PLATE, DOOR HINGE

SN: P076093--UP

2шт.

|$62

24 891 R1

BOLT, MOUNTING - 3/4NCx2-3/4

SN: P076093--UP

2шт.

|$63

25 548 R1

WASHER, FLAT - 3/4

SN: P076093--UP

4шт.

|$64

9413 983

NUT. LOCK - 3/4

SN: P076093--UP

2шт.

27

GUARD, TRANSMISSION (SEE FIG. J2110-01A1)

SN: P076093--UP

1шт.

28

GUARD, CRANKCASE (SEE FIG. J2110-01A1)

SN: P076093--UP

1шт.

29

TRUNNION, LEFT (SEE FIG. T2110-01A0)

SN: P076093--UP

1шт.

30

TRUNNION, RIGHT (SEE FIG. T2110-01A0)

SN: P076093--UP

1шт.

31

1312 918 H92

GRABHANDLE

SN: P076093--UP

2шт.

|$70

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P076093--UP

4шт.

|$71

25 544 R1

WASHER, FLAT 3/8

SN: P076093--UP

4шт.

|$72

-1шт.

|$73

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$74

-1шт.

|$75

-1шт.

|$76

F2 - SERVICE PART WILL BE AVAILABLE ON SPECIAL ORDER WITH THE CLEARANCE OF THE ENGINEERING DEPARTMENT. PRODUCT IDENTIFICATION NUMBER (PIN) MUST BE FURNISHED WHEN ORDERING. ORDER ON MACHINE ORDER FORM.

-1шт.

|$77

-1шт.
