Запчасти Komatsu D32E-1A FIG. H-A ГИДРОЛИНИЯ - РЫХЛИТЕЛЬ ГИДРАВЛИКА

|$0

1281 350 H91

RIPPER PIPING

SN: P076093--UP

1шт.

1

9410 204

CONNECTOR

SN: P076093--UP

2шт.

|$2

364 885 R1

RING, SEAL

SN: P076093--UP

2шт.

2

1249 049 H1

TUBE, LEFT CYLINDER

SN: P076093--UP

1шт.

3

1249 048 H1

TUBE, RIGHT CYLINDER

SN: P076093--UP

1шт.

4

1249 051 H1

HOSE, CROSSOVER

SN: P076093--UP

2шт.

5

9410 978

ELBOW - 90°

SN: P076093--UP

4шт.

|$7

364 885 R1

RING, SEAL

SN: P076093--UP

4шт.

6

9410 334

TEE

SN: P076093--UP

1шт.

7

1281 357 H1

HOSE, VALVE TO CYLINDER

SN: P076093--UP

2шт.

8

326 078 R1

CLAMP, HOSE

SN: P076093--UP

1шт.

|$11

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P076093--UP

1шт.

|$12

25 534 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$13

25 522 R1

NUT, HEX - 3/8NC

SN: P076093--UP

1шт.

9

1281 435 H1

BRACKET, HOSE

SN: P076093--UP

1шт.

|$15

24 842 R1

BOLT, HEX - 3/8NCx1-3/4

SN: P076093--UP

1шт.

|$16

25 544 R1

WASHER, FLAT - 3/8

SN: P076093--UP

1шт.

10

CYLINDER, RIPPER (SEE FIG. T2450-01A0)

SN: P076093--UP

2шт.

|$18

-1шт.

|$19

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$20

-1шт.
