Запчасти Komatsu D32E-1A FIG. H-A ГИДРОЛИНИЯ - DE-A - ОТВАЛ ANGLE ГИДРАВЛИКА

1

VALVE, 3 SPOOL (SEE FIG. H0120-01A0)

SN: P076093--UP

1шт.

|$2

OR

-1шт.

|$4

VALVE, 4 SPOOL (SEE FIG. H0120-02A0)

SN: P076093--UP

1шт.

2

9410 204

CONNECTOR

SN: P076093--UP

2шт.

|$6

364 885 R1

RING, SEAL

SN: P076093--UP

2шт.

3

1271 306 H1

TUBE, ROD ANGLE

SN: P076093--UP

1шт.

4

1271 307 H1

TUBE, HEAD ANGLE

SN: P076093--UP

1шт.

5

1271 311 H1

BRACKET, TUBE SUPPORT

SN: P076093--UP

1шт.

|$10

24 860 R1

BOLT, HEX - 1/2NCx1

SN: P076093--UP

1шт.

|$11

25 546 R1

WASHER, FLAT - 1/2

SN: P076093--UP

1шт.

6

653 236 C1

CLAMP, TUBE

SN: P076093--UP

1шт.

|$13

24 842 R1

BOLT, HEX - 3/8NCx1-3/4

SN: P076093--UP

1шт.

|$14

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$15

25 522 R1

NUT, HEX - 3/8NC

SN: P076093--UP

1шт.

|$16

26 241 H

SPACER - 3/8x3/4

SN: P076093--UP

1шт.

7

134 794 H1

HOSE, TO TEE

SN: P076093--UP

2шт.

8

9410 333

TEE, SWIVEL

SN: P076093--UP

2шт.

9

1271 351 H1

HOSE, ANGLE CROSSOVER

SN: P076093--UP

2шт.

10

9410 203

CONNECTOR

SN: P076093--UP

8шт.

|$21

570 828 R1

RING, SEAL

SN: P076093--UP

8шт.

11

1271 357 H1

HOSE, ROD ANGLE

SN: P076093--UP

2шт.

12

1271 358 H1

HOSE, HEAD ANGLE

SN: P076093--UP

2шт.

13

653 171 C1

CLAMP, TUBE

SN: P076093--UP

4шт.

|$25

24 843 R1

BOLT, HEX - 3/8NCx2

SN: P076093--UP

2шт.

|$26

25 544 R1

WASHER, FLAT - 3/8

SN: P076093--UP

4шт.

|$27

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$28

26 241 H

SPACER

SN: P076093--UP

4шт.

14

9410 203

CONNECTOR

SN: P076093--UP

4шт.

|$30

570 828 R1

RING, SEAL

SN: P076093--UP

4шт.

15

1306 638 H91

GUARD, HOSE

SN: P076093--UP

2шт.

|$32

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

6шт.

|$33

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P076093--UP

6шт.

16

CYLINDER, ANGLE (SEE FIG. T2190-01A0)

SN: P076093--UP

2шт.

|$35

306 132 C2

STRAP, TIE

SN: P076093--UP

-2шт.
