Запчасти Komatsu D32E-1A FIG. H-A ГИДРОЛИНИЯ - DE-A - ПОДЪЕМ. ОТВАЛА ГИДРАВЛИКА

1

VALVE, 3 SPOOL (SEE FIG. H0120-01A0)

SN: P076093--UP

1шт.

|$2

OR

-1шт.

|$4

VALVE, 4 SPOOL (SEE FIG. H0120-02A0)

SN: P076093--UP

1шт.

2

9410 204

CONNECTOR

SN: P076093--UP

2шт.

|$6

364 885 R1

RING, SEAL

SN: P076093--UP

2шт.

|$7

1285 292 H1

VENT, ORIFICE-0.281 IN TOP PORT ROD END

SN: P076093--UP

1шт.

3

1271 300 H1

TUBE, ROD LIFT

SN: P076093--UP

1шт.

4

1271 301 H1

TUBE, HEAD LIFT

SN: P076093--UP

1шт.

5

1271 302 H1

TUBE, ROD END CROSSOVER

SN: P076093--UP

1шт.

6

1271 303 H1

TUBE, HEAD END CROSSOVER

SN: P076093--UP

1шт.

7

653 171 C1

CLAMP, CROSSOVER TUBE

SN: P076093--UP

1шт.

|$13

140 483 H

BOLT, HEX - 3/8NCx1-1/4

SN: P076093--UP

1шт.

|$14

25 544 R1

WASHER, FLAT - 3/8

SN: P076093--UP

1шт.

8

1271 310 H1

BRACKET SUPPORT

SN: P076093--UP

1шт.

9

1271 346 H1

HOSE, LH ROD END

SN: P076093--UP

2шт.

10

1271 345 H1

HOSE, RH HEAD END

SN: P076093--UP

2шт.

11

653 171 C1

CLAMP, HOSE

SN: P076093--UP

2шт.

|$19

24 843 R1

BOLT, HEX - 3/8NCx2

SN: P076093--UP

2шт.

|$20

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$21

25 544 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$22

26 241 H

SPACER, CLAMP

SN: P076093--UP

2шт.

|$23

25 522 R1

NUT, HEX - 3/8NC

SN: P076093--UP

2шт.

12

1277 460 H91

TUBE, RIGHT ROD END

SN: P076093--UP

1шт.

|$25

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$26

25 522 R1

NUT, HEX - 3/8NC

SN: P076093--UP

1шт.

13

1277 461 H91

TUBE, LEFT ROD END

SN: P076093--UP

1шт.

|$28

25 553 R1

WASHER, FLAT - 3/8

SN: P076093--UP

2шт.

|$29

25 522 R1

NUT, HEX - 3/8NC

SN: P076093--UP

1шт.

14

9410 204

CONNECTOR

SN: P076093--UP

4шт.

|$31

364 885 R1

RING, SEAL

SN: P076093--UP

4шт.

15

CYLINDER, LIFT (SEE FIG. T2170-01A0)

SN: P076093--UP

2шт.

|$33

306 132 C2

STRAP, TIE

SN: P076093--UP

-2шт.
