Запчасти Komatsu D32E-1A FIG. H-A ПЕРЕКОС. ОТВАЛА SECTION ГИДРАВЛИКА

|$0

1299 224 H91

SECTION ASSEMBLY, BLADE TILT

SN: P076093--UP

1шт.

1

POSITIONER (SEE FIG. H0120-08A0)

SN: P076093--UP

1шт.

2

VALVE, LOAD CHECK (SEE FIG. H0120-09A0)

SN: P076093--UP

2шт.

3

1299 238 H91

SEAL ASSEMBLY, SPOOL

SN: P076093--UP

2шт.

|$4

850 880 C1

RETAINER, SEAL

SN: P076093--UP

1шт.

|$5

1299 239 H1

KIT, SEAL

SN: P076093--UP

1шт.

4

NSS

RING, BACK UP

SN: P076093--UP

1шт.

5

NSS

RING, SEAL

SN: P076093--UP

1шт.

6

1299 240 H1

KIT, SEAL PLATE

SN: P076093--UP

1шт.

|$9

NSS

PLATE, SEAL

SN: P076093--UP

1шт.

7

NSS

BOLT, HEX - 1/4NCx1/2

SN: P076093--UP

2шт.

|$11

NSS

SPOOL, SECTION

SN: P076093--UP

1шт.

8

NSS

HOUSING, SECTION

SN: P076093--UP

1шт.

|$13

-1шт.

|$14

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$16

-1шт.

|$17

F2 - FOR SHIPPING PURPOSES ONLY. USE FOR SERVICING SECTION.

-1шт.

|$18

-1шт.
