Запчасти Komatsu D32E-1A FIG. F-A ГИДРОТРАНСФОРМАТОР - ONE ЧАСТИ КОЖУХ - COMPLETE ASSEMBLY СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1312 194 H91

CONVERTER ASSEMBLY, TORQUE

SN: P076093--UP

1шт.

1

1311 155 H1

TURBINE

SN: P076093--UP

1шт.

2

1311 156 H1

DISC, COUPLING

SN: P076093--UP

1шт.

3

1311 154 H1

HOUSING, ONE PIECE

SN: P076093--UP

1шт.

4

1311 158 H1

IMPELLER

SN: P076093--UP

1шт.

5

01252-60820

BOLT, SOCKET HEAD HEX M8X20

SN: P076093--UP

12шт.

6

1500 158 H1

WASHER, PLATE

SN: P076093--UP

1шт.

7

1311 157 H1

STATOR

SN: P076093--UP

1шт.

8

1311 159 H1

HUB, STATOR

SN: P076093--UP

1шт.

9

30 022 R1

BOLT, HEX - M10x35

SN: P076093--UP

6шт.

10

30 176 R1

WASHER, M10

SN: P076093--UP

6шт.

11

1311 160 H1

SHAFT, OUTPUT

SN: P076093--UP

1шт.

12

1311 161 H1

GEAR, DRIVE

SN: P076093--UP

1шт.

13

1311 162 H1

COVER, HUB

SN: P076093--UP

1шт.

14

30 003 R1

BOLT, HEX - M8x25

SN: P076093--UP

6шт.

15

30 175 R1

WASHER, M8

SN: P076093--UP

6шт.

16

1311 163 H1

RETAINER, YOKE

SN: P076093--UP

1шт.

17

30 050 R1

BOLT, HEX - M12x70

SN: P076093--UP

1шт.

18

30 177 R1

WASHER, LOCK - M12

SN: P076093--UP

1шт.

19

1311 164 H1

GASKET

SN: P076093--UP

1шт.

20

1311 165 H1

RING, SEAL

SN: P076093--UP

1шт.

21

1311 241 H2

YOKE, OUTPUT

SN: P076093--UP

1шт.

22

1311 167 H1

GEAR, PUMP DRIVE

SN: P076093--UP

2шт.

23

1311 168 H1

RING, SPACER

SN: P076093--UP

1шт.

24

1311 169 H1

SHIM, COVER

SN: P076093--UP

-2шт.

25

1311 170 H1

HOUSING, DRIVE

SN: P076093--UP

1шт.

26

30 005 R1

BOLT, HEX - M8x35

SN: P076093--UP

24шт.

27

30 175 R1

WASHER, M8

SN: P076093--UP

24шт.

28

1311 171 H1

ENCLOSURE, INTERNAL

SN: P076093--UP

1шт.

29

30 002 R1

BOLT, HEX - M8x20

SN: P076093--UP

12шт.

30

30 175 R1

WASHER, M8

SN: P076093--UP

12шт.

31

1311 172 H1

PLATE, LOCK

SN: P076093--UP

1шт.

32

30 019 R1

BOLT, HEX - M10x20

SN: P076093--UP

6шт.

33

1311 173 H1

RING, THRUST

SN: P076093--UP

1шт.

34

1311 174 H1

RING, SEAL

SN: P076093--UP

1шт.

35

ST 265

BEARING, BALL

SN: P076093--UP

1шт.

36

205 368 R91

BEARING, BALL

SN: P076093--UP

1шт.

37

ST 235

BEARING, BALL

SN: P076093--UP

1шт.

38

ST 205 A

BEARING, BALL

SN: P076093--UP

2шт.

39

1311 237 H1

BEARING, ROLLER

SN: P076093--UP

2шт.

40

1311 236 H1

BEARING, THRUST ROLLER

SN: P076093--UP

2шт.

41

1501 139 H1

O-RING 280x3

SN: P076093--UP

1шт.

42

1501 140 H1

O-RING 320x3

SN: P076093--UP

1шт.

43

1501 162 H1

O-RING 125x3

SN: P076093--UP

1шт.

44

1501 138 H1

O-RING 28x3

SN: P076093--UP

1шт.

45

1311 232 H1

SEAL, OIL

SN: P076093--UP

1шт.

46

1311 231 H1

SEAL, OIL

SN: P076093--UP

1шт.

47

933 029 R1

RING, RETAINING

SN: P076093--UP

2шт.

48

933 075 R1

RING, RETAINING

SN: P076093--UP

1шт.

49

933 076 R1

RING, RETAINING

SN: P076093--UP

4шт.

50

933 077 R1

RING, RETAINING

SN: P076093--UP

1шт.

|$51

-1шт.

|$52

F1 - OPTIONAL WITH TWO PIECE HOUSING CONVERTER 312 104 H91. (SEE FIG. F2310-51A0)

-1шт.

|$53

-1шт.
