Запчасти Komatsu D32E-1 БЛОК ЦИЛИНДРОВ - METRIC РЕЗЬБАS POWER - DE-

|$0

6731-21-1130

BLOCK ASSEMBLY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6732-21-1910

DOWEL, RING

10шт.

3

6732-21-1810

PLUG, EXPANSION

3шт.

4

6731-21-1230

CAP, BEARING

5шт.

5

6736-21-1820

PLUG, EXPANSION

2шт.

6

6735-21-5530

PLUG, EXPANSION

2шт.

7

6736-21-1810

PLUG, EXPANSION

3шт.

8

6732-21-1611

BOLT

10шт.

9

6732-21-1411

BUSHING

1шт.

10

6732-11-1910

PLUG, PIPE

1шт.

11

6732-11-1920

PLUG, PIPE

1шт.

|$12

6732-21-1960

PLUG, THREADED

2шт.

12

NSS

PLUG

1шт.

13

6215-81-9710

SEAL, O-RING

1шт.

14

6732-21-6120

DOWEL, PIN

2шт.

15

6732-21-6130

PLUG, EXPANSION

1шт.

16

6732-21-6140

DOWEL, RING

2шт.

17

6732-21-1930

SEAL, O-RING

1шт.

18

6732-21-1191

NOZZLE, PISTON COOLING

4шт.

19

6732-21-6160

PLUG, EXPANSION

1шт.

20

6736-29-2110

SLEEVE, SALVAGE

1шт.

|$24

-1шт.

|$25

6731-21-1220

KIT, CYLINDER BLOCK HARDWARE

1шт.

|$26

-1шт.

|$27

-1шт.

|$28

F1 - THESE ITEMS ARE INCLUDED IN THE CYLINDER BLOCK HARDWARE KIT (6731-21-1220)

-1шт.
