Запчасти Komatsu D32E-1 LUBRICATED ГУСЕНИЦЫ СИСТЕМА - DE- ОДИНОЧН. NOTCH МАЧТАER СОЕДИНИТЕЛЬН. ЗВЕНО КОЛЕСА И TRACTION

|$0

1306 623 H91

LUBRICATED TRACK SYSTEM

-54шт.

|$1

1237 164 H93

CHAIN ASSY, TRACK

2шт.

1

1236 887 H1

LINK, RIGHT MASTER - PIN END

1шт.

2

1236 886 H1

LINK, LEFT MASTER - PIN END

1шт.

3

1237 191 H1

BUSHING, CHAIN LINK

34шт.

4

1237 193 H1

PIN, CHAIN LINK

34шт.

5

1237 196 H1

WASHER, THRUST

68шт.

6

1236 891 H1

LINK, RIGHT CHAIN

33шт.

7

1236 890 H1

LINK, LEFT CHAIN

33шт.

8

1236 888 H1

LINK, LEFT MASTER - BUSHING END

1шт.

9

1236 889 H1

LINK, RIGHT MASTER - BUSHING END

1шт.

10

739 158 C1

PLUG, PIN

34шт.

11

1252 955 H91

SEAL, CHAIN

68шт.

|$13

1236 990 H2

BOLT, MASTER LINK TRACK SHOE

4шт.

|$14

1237 162 H93

CHAIN WITH 15IN SHOES

2шт.

|$15

CHAIN, TRACK - SEE ABOVE

1шт.

|$16

1236 985 H1

SHOE, TRACK (SEE PG 15-002)

-29шт.

|$17

616 199 C4

BOLT, TRACK SHOE

132шт.

|$18

616 200 C1

NUT, SHOE BOLT

132шт.

|$19

1237 159 H93

CHAIN WITH 15IN SHOES - MUD RELIEF

2шт.

|$20

CHAIN, TRACK - SEE ABOVE

1шт.

|$21

1237 418 H1

SHOE, TRACK (SEE PG 15-002)

-29шт.

|$22

616 199 C4

BOLT, TRACK SHOE

132шт.

|$23

616 200 C1

NUT, SHOE BOLT

132шт.

|$24

1270 589 H91

CHAIN WITH 17IN SHOES

2шт.

|$25

CHAIN, TRACK - SEE ABOVE

1шт.

|$26

1270 460 H1

SHOE, TRACK (SEE PG 15-004)

-29шт.

|$27

616 199 C4

BOLT, TRACK SHOE

132шт.

|$28

616 200 C1

NUT, SHOE BOLT

132шт.

|$$30

-1шт.

|$30

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$32

-1шт.
