Запчасти Komatsu D32E-1 IN ГУСЕНИЦЫS DP- КОЛЕСА И TRACTION

|$0

1281 168 H91

TRACK SHOES, 24 IN

-54шт.

1

1236 987 H1

SHOE, TRACK

74шт.

2

616 199 C4

BOLT, TRACK SHOE

288шт.

3

616 200 C1

NUT, TRACK SHOE

288шт.

4

1258 970 H91

BAR, C-FRAME RUB

2шт.

|$5

24 876 R1

BOLT, HEX - 5/8NCx2-1/4

8шт.

|$6

25 547 R1

WASHER, FLAT - 5/8

8шт.

5

1271 387 H1

PLATE, RUB BAR

2шт.

6

1258 997 H1

SHIM, RUB BAR

-2шт.

7

1281 017 H1

STEP, FOOT

2шт.

|$10

24 874 R1

BOLT, HEX - 5/8NCx1-3/4

4шт.

|$11

25 537 R1

WASHER, FLAT - 5/8

8шт.

|$12

25 528 R1

NUT, HEX - 5/8NC

4шт.

8

BOLT, MASTER LINK (SEE PG 15-014)

-29шт.

|$$15

-1шт.

|$15

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$17

-1шт.
