Запчасти Komatsu D32E-1 СИДЕНЬЕ КРЕПЛЕНИЕ КАБИНА ROPS SUPERSTRUCTURE

1

SEAT, SUSPENSION (SEE PG 13-028)

-29шт.

|$1

25 552 R1

WASHER, FLAT - 5/16

4шт.

|$2

25 520 R1

NUT, HEX - 5/16NC

4шт.

2

1309 250 H91

ARM REST

2шт.

|$4

24 839 R1

BOLT, HEX - 3/8NCx3/4

4шт.

|$5

25 534 R1

WASHER, FLAT - 3/8

4шт.

3

1309 249 H1

BRACKET, MOUNTING

2шт.

|$7

24 839 R1

BOLT, HEX - 3/8NCx3/4

4шт.

|$8

25 534 R1

WASHER, FLAT - 3/8

4шт.

4

PLATE, SEAT MOUNTING (SEE PG 13-086)

-29шт.

|$10

24 840 R1

BOLT, HEX - 3/8NCx1

6шт.

|$11

25 553 R1

WASHER, FLAT - 3/8

6шт.

|$12

24 860 R1

BOLT, HEX - 1/2NCx1

3шт.

|$13

25 555 R1

WASHER, FLAT - 1/2

3шт.

5

SUPPORT, FRONT SEAT (SEE PG 13-086)

-29шт.

|$15

24 848 R1

BOLT, HEX - 7/16NCx3/4

4шт.

|$16

25 553 R1

WASHER, FLAT - 3/8

4шт.

6

3071 294 R1

BOSS, MOUNTING - TUBE CLAMP

1шт.

7

1300 689 H1

BAR, SEAT MOUNTING

2шт.

|$19

24 840 R1

BOLT, HEX - 3/8NCx1

4шт.

|$20

25 553 R1

WASHER, FLAT - 3/8

4шт.

8

636 888 C3

BELT, SEAT

1шт.

|$22

24 864 R1

BOLT, HEX - 1/2NCx2

2шт.

|$23

25 555 R1

WASHER, FLAT - 1/2

4шт.

|$24

9412 230

NUT, LOCK - 1/2NC

2шт.

9

1287 385 H1

SLEEVE, EXTRUDED

2шт.

10

610 395 R1

SPACER, PIPE

4шт.
