Запчасти Komatsu D32E-1 КАПОТ, ПАНЕЛЬS, СУППОРТS И DASH С СИСТЕМОЙ ROPS SUPERSTRUCTURE

|$0

1306 412 H91

HOOD, PANELS, SUPPORTS AND DASH

-54шт.

1

1306 614 H91

DASHBOARD

1шт.

|$2

24 861 R1

BOLT, HEX - 1/2NCx1-1/4

6шт.

|$3

25 546 R1

WASHER, FLAT - 1/2

6шт.

2

1286 760 H2

SHIM, MOUNTING

-2шт.

3

1269 067 H91

GUARD, INSTRUMENT PANEL

1шт.

4

1269 052 H1

BOLT, SHOULDER

2шт.

5

1278 359 H1

WASHER, SPACER

2шт.

6

SEAL, ABSORBER - 12IN LONG

1шт.

7

DOOR, LEFT SIDE (SEE PG 13-014)

-29шт.

|$10

26 309 R1

BOLT, HEX - 3/8NCx3/4

3шт.

|$11

25 553 R1

WASHER, FLAT - 3/8

3шт.

|$12

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

2шт.

|$13

25 555 R1

WASHER, FLAT - 1/2

2шт.

8

DOOR, RIGHT SIDE (SEE PG 13-014)

-29шт.

|$15

26 309 R1

BOLT, HEX - 3/8NCx3/4

3шт.

|$16

25 553 R1

WASHER, FLAT - 3/8

3шт.

|$17

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

2шт.

|$18

25 555 R1

WASHER, FLAT - 1/2

2шт.

9

679 070 C1

INSULATOR, AIR STACK

1шт.

10

1277 041 H91

COVER, REAR

1шт.

|$21

24 860 R1

BOLT, HEX - 1/2NCx1

2шт.

|$22

25 546 R1

WASHER, FLAT - 1/2

2шт.

11

1277 043 H1

COVER, ACCESS

1шт.

|$24

24 839 R1

BOLT, HEX - 3/8NCx3/4

1шт.

|$25

25 534 R1

WASHER, FLAT - 3/8

1шт.

|$26

126 032

NUT, WING - 3/8NC

1шт.

12

1281 995 H92

BRACKET, HOOD TIE DOWN

2шт.

|$28

25 483 R1

BOLT, HEX - 1/4NCx1

4шт.

|$29

25 542 R1

WASHER, FLAT - 1/4

4шт.

13

1281 994 H1

ROD, TIE DOWN

2шт.

|$31

25 543 R1

WASHER, FLAT - 5/16

4шт.

|$32

9413 952

NUT, LOCK - 5/16NC

2шт.

14

617 867 C1

BALL, COMPRESSION

2шт.

15

1308 145 H1

BAR, DASH BRACE

2шт.

|$35

24 860 R1

BOLT, HEX - 1/2NCx1

4шт.

|$36

25 546 R1

WASHER, FLAT - 1/2

4шт.

16

1306 327 H91

COWL, DASH

1шт.

|$38

24 840 R1

BOLT, HEX - 3/8NCx1

6шт.

|$39

25 534 R1

WASHER, FLAT - 3/8

6шт.

17

27 951 R1

PLUG, FRONT LIGHTS BUTTON

4шт.

18

HOOD, SOLID (SEE PG 13-010)

-29шт.

|$42

24 859 R1

BOLT, HEX - 1/2NCx3/4

3шт.

|$43

106 265

WASHER, FLAT - 9/16

3шт.

18

HOOD, PERFORATED (SEE PG 13-012)

-29шт.

|$45

24 859 R1

BOLT, HEX - 1/2NCx3/4

3шт.

|$46

106 265

WASHER, FLAT - 9/16

3шт.

19

PADLOCK WITH KEYS (SEE PG 02-010)

-29шт.

|$48

1136 356 C1

SEAL, BULK

-2шт.

|$$50

-1шт.

|$50

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$52

-1шт.

|$$53

-1шт.

|$53

F2 - CUT REQUIRED LENGTH FROM BULK SEAL 1136 356 C1.

-1шт.

|$$55

-1шт.
