Запчасти Komatsu D32E-1 SHOES И РЫЧАГИ ТОРМОЗ.S

1

SHOE, APPLY (SEE PG 04-016)

-29шт.

2

621 025 C1

SHAFT, ECCENTRIC

4шт.

3

621 026 C1

WASHER, THRUST

8шт.

4

621 027 C1

ARM, LEFT STEERING

1шт.

5

621 028 C1

ARM, RIGHT STEERING

1шт.

6

621 032 C1

ARM, LEFT BRAKE

1шт.

7

621 033 C1

ARM, RIGHT BRAKE

1шт.

8

621 036 C1

RING, RETAINING

4шт.

9

SHOE, BACK UP (SEE PG 04-016)

-29шт.

10

360 677 R1

SPRING, ARM RETURN

2шт.

11

621 039 C1

SCREW, STEERING SHOE ADJUSTMENT

2шт.

12

621 822 C1

PLATE, SCREW LOCK

2шт.

|$12

24 839 R1

BOLT, HEX - 3/8NCx3/4

2шт.

|$13

120 930

WASHER, LOCK - 3/8

2шт.

13

621 040 C1

SCREW, BRAKE SHOE ADJUSTMENT

2шт.

|$15

219 760

NUT, JAM - 1NF

2шт.

|$16

733 233 C92

PLATE ASSY, LEFT MOUNTING

1шт.

|$17

733 225 C92

PLATE ASSY, LEFT

-54шт.

14

NSS

PLATE, LEFT

1шт.

15

621 087 C1

PIN, DOWEL

2шт.

16

621 090 C91

BEARING, NEEDLE

2шт.

|$21

24 864 R1

BOLT, HEX - 1/2NCx2

3шт.

|$22

25 546 R1

WASHER, FLAT - 1/2

3шт.

|$23

733 234 C92

PLATE ASSY, RIGHT MOUNTING

1шт.

|$24

733 226 C92

PLATE ASSY, RIGHT

-54шт.

17

NSS

PLATE, RIGHT

1шт.

18

621 087 C1

PIN, DOWEL

2шт.

19

621 090 C91

BEARING, NEEDLE

2шт.

|$28

24 864 R1

BOLT, HEX - 1/2NCx2

3шт.

|$29

25 546 R1

WASHER, FLAT - 1/2

3шт.

20

733 227 C1

SPACER, PLATE MOUNTING

4шт.

|$$32

-1шт.

|$32

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$34

-1шт.
