Запчасти Komatsu D32E-1 ТОПЛИВН. ТРУБЫ POWER

1

1240 129 H1

SEAL, GROMMET

2шт.

2

1294 781 H1

BOLT - M5x22

4шт.

3

6732-71-6230

SEAL, BANJO CONNECTOR

4шт.

4

1278 262 H1

BOLT - M8x25

2шт.

5

6732-71-6240

SCREW, BANJO CONNECTOR - M6x14

4шт.

6

1240 342 H1

TEE, MALE UNION

1шт.

7

1240 749 H91

TUBE, FUEL DRAIN

1шт.

|$7

1271 332 H1

SEAL, GROMMET

1шт.

8

1282 276 H1

TUBE, FUEL DRAIN

1шт.

|$9

1271 332 H1

SEAL, GROMMET

1шт.

9

1294 781 H1

BOLT - M5x22

4шт.

10

1240 227 H1

WASHER, PLAIN

4шт.

11

1295 756 H1

BRACE, TUBE

1шт.

12

6735-71-5820

BRACE, TUBE

4шт.

13

6735-71-5860

ISOLATOR, VIBRATION

8шт.

14

1240 639 H1

TUBE, INJECTOR FUEL SUPPLY (NO. 1 CYLINDER)

1шт.

15

1240 640 H1

TUBE, INJECTOR FUEL SUPPLY (NO. 2 CYLINDER)

1шт.

16

1295 757 H1

BRACE, TUBE

1шт.

17

1240 641 H1

TUBE, INJECTOR FUEL SUPPLY (NO. 3 CYLINDER)

1шт.

18

1240 642 H1

TUBE, INJECTOR FUEL SUPPLY (NO. 4 CYLINDER)

1шт.

19

1240 850 H1

MANIFOLD, FUEL

1шт.

20

1271 332 H1

SEAL, GROMMET

1шт.

21

1294 783 H1

BRACE, TUBE

1шт.

22

1295 758 H1

BRACE, TUBE

1шт.
