Запчасти Komatsu D32E-1 ГОЛОВКА ЦИЛИНДРОВ POWER

|$0

1295 764 H91

HEAD, CYLINDER

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

6736-11-1160

PLUG, EXPANSION

3шт.

3

6732-11-1930

PLUG, PIPE

2шт.

4

6732-11-1910

PLUG, PIPE

5шт.

|$5

6736-41-4110

VALVE, INTAKE

4шт.

5

NSS

VALVE, INTAKE

4шт.

6

6732-41-4520

COLLET, VALVE

8шт.

|$8

6736-41-4210

VALVE, EXHAUST

4шт.

7

NSS

VALVE, EXHAUST

4шт.

6

6732-41-4520

COLLET, VALVE

8шт.

8

1240 164 H2

SEAL, VALVE STEM

8шт.

9

6735-41-4410

SPRING, VALVE

8шт.

10

6732-41-4510

RETAINER, VALVE SPRING

8шт.

11

6732-11-1620

BOLT - M12x120

10шт.

12

6732-11-1610

BOLT - M12x70

4шт.

13

6732-11-1810

GASKET, CYLINDER HEAD (STD)

1шт.

|$17

1295 467 H3

GASKET, CYLINDER HEAD - 0.25MM OVERSIZE

-2шт.

|$18

1240 785 H4

GASKET, CYLINDER HEAD - 0.50MM OVERSIZE

-2шт.

14

6736-19-1440

INSERT, VALVE (EXHAUST)

-2шт.

15

6736-19-1430

INSERT, VALVE (INTAKE)

-2шт.

16

6736-19-1310

GUIDE, VALVE (THICK WALL 60.5MM LONG INTAKE)

-2шт.

17

6736-19-1410

GUIDE, VALVE (THICK WALL 51.75MM LONG EXHAUST)

-2шт.

18

6736-18-1310

GUIDE, VALVE (THIN WALL, INTAKE OR EXHAUST)

-2шт.

|$$25

-1шт.

|$25

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$26

ASSEMBLIES CATALOG.

-1шт.
