Запчасти Komatsu D32E-1 ТОПЛ. БАК И ТОПЛИВОПРОВОД POWER

|$0

1278 006 H91

FUEL PIPING

-54шт.

1

1277 935 H1

ELBOW, RETURN

1шт.

2

336 085 R91

HOSE, FUEL RETURN

1шт.

3

9402 747

CONNECTOR

1шт.

4

444 024

BUSHING, REDUCER

1шт.

5

140 353

CONNECTOR ASSY

1шт.

|$6

140 284

CONECTOR

1шт.

|$7

121 322

SLEEVE, TUBE

1шт.

|$8

121 220

NUT, FLARED TUBE

1шт.

6

111 316

ELBOW, SUPPLY

1шт.

7

627 686 C1

VALVE, SHUT OFF - OPTIONAL

1шт.

7

1301 358 H1

VALVE, SHUT OFF - OPTIONAL

1шт.

|$12

444 002

ADAPTER, PIPE - 3/8

2шт.

8

176 057 H1

FITTING, HOSE

1шт.

9

HOSE, FUEL SUPPLY - 82IN LONG

1шт.

10

279 025 R91

CLAMP, HOSE

4шт.

11

1243 000 H1

STRAINER, FUEL

1шт.

12

HOSE, SUPPLY - 2IN LONG

1шт.

13

441 190 C1

ELBOW, SUPPLY

1шт.

14

323 413 R1

CLIP, CLOSED

2шт.

|$20

24 839 R1

BOLT, HEX - 3/8NCx3/4

1шт.

|$21

25 544 R1

WASHER, FLAT - 3/8

2шт.

15

443 980

NIPPLE, PIPE

1шт.

16

1301 358 H1

VALVE, DRAIN

1шт.

|$24

935 522 C1

STRAP, TIE

-2шт.

17

308 860 R1

CLIP, HOSE

1шт.

|$26

30 041 R1

BOLT, HEX - M12x25

1шт.

|$27

30 177 R1

WASHER, FLAT - M12

1шт.

18

HOSE, DRAIN - 4IN LONG

1шт.

|$29

1306 328 H91

FUEL TANK MOUNTING

-54шт.

19

1278 469 H1

DIPSTICK

1шт.

|$31

1306 329 H91

TANK ASSY, FUEL

-54шт.

|$32

701 922 C2

CAP ASSY, FILLER

1шт.

20

NSS

CAP, FILLER

1шт.

21

618 688 C3

GASKET, CAP

1шт.

22

1306 251 H91

TANK, FUEL

1шт.

|$36

24 888 R1

BOLT, HEX - 3/4NCx2

2шт.

|$37

25 538 R1

WASHER, FLAT - 3/4

2шт.

23

1278 012 H2

STRAINER, FUEL

1шт.

24

1285 270 H1

SPACER, MOUNTING

2шт.

25

1306 244 H1

PLATE, COVER

1шт.

26

1306 245 H1

GASKET

1шт.

|$42

25 228 R1

BOLT, HEX - 5/16NCx3/4

4шт.

|$43

25 533 R1

WASHER, FLAT - 5/16

4шт.

27

1305 707 H1

SENDER, FUEL LEVEL

1шт.

|$45

1280 602 H1

SCREW, MOUNTING - #10NFx1

5шт.

|$46

120 391

WASHER, FLAT - #10

5шт.

28

CAP, LOCKING (SEE PG 02-010)

-29шт.

|$48

706 670 C1

HOSE, BULK

-2шт.

|$$50

-1шт.

|$50

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$52

-1шт.

|$$53

-1шт.

|$53

F2 - USED ONLY WITH DRAIN VALVE 1301 358 H1.

-1шт.

|$$55

-1шт.

|$$56

-1шт.

|$56

F3 - CUT REQUIRED LENGTH FROM BULK HOSE 706 670 C1.

-1шт.

|$$58

-1шт.
