Запчасти Komatsu D32E-1 УПРАВЛ-Е ДВИГАТЕЛЕМS POWER

|$0

1308 103 H91

ENGINE CONTROLS

-54шт.

1

104 038

CLEVIS, ROD END

1шт.

|$2

25 487 R1

BOLT, HEX - 1/4NCx1-1/2

1шт.

|$3

25 532 R1

WASHER, FLAT - 1/4

4шт.

|$4

26 110 R1

NUT, LOCK - 1/4NC

1шт.

2

1279 059 H1

CLAMP, SPACER

2шт.

3

281 800 C92

JOINT, BALL - 1/4NF

1шт.

|$7

28 232 R1

SCREW, SET - 1/4NF

1шт.

|$8

27 122 R1

NUT, LOCK - 1/4NF

1шт.

4

1280 178 H1

CONNECTOR, REDUCER

1шт.

5

1268 399 H1

ROD, PUMP CONTROL

1шт.

|$11

25 523 R1

NUT, CONNECTOR - 3/8NF

2шт.

6

114-43-48220

LEVER, CONTROL

1шт.

|$13

140 183

SCREW, MOUNTING - 3/8NCx1-1/4

2шт.

|$14

25 534 R1

WASHER, FLAT - 3/8

2шт.

|$15

103 384

PIN, COTTER

1шт.

7

203-43-44360

KNOB, CONTROL LEVER

1шт.

8

1281 116 H1

SHAFT, THROTTLE

1шт.

|$18

19 795 R1

PIN, ROLL

1шт.

9

CONTROL, THROTTLE (SEE PG 12-016)

-29шт.

10

BELLCRANK, THROTTLE (SEE PG 12-016)

-29шт.

11

114-43-48381

GROMMET

1шт.

12

740 528 C1

BOLT, ADJUSTING

2шт.

|$23

25 522 R1

NUT, HEX - 3/6NC

2шт.

13

DECELERATOR, OVER TRAVEL (SEE PG 12-018)

-29шт.

|$25

16 617 R1

PIN, CLEVIS - 3/8x1-1/6

1шт.

|$26

103 373

PIN, COTTER - 3/32x3/4

1шт.

14

THROTTLE, OVER TRAVEL (SEE PG 12-020)

-29шт.

|$28

16 617 R1

PIN, CLEVIS - 3/8x1-1/6

1шт.

|$29

103 373

PIN, COTTER - 3/32x3/4

1шт.

15

1258 327 H91

CABLE, THROTTLE

1шт.

|$31

26 030 R1

NUT, HEX - 1/4NF

1шт.

16

281 800 C92

JOINT, BALL - 1/4NF

1шт.

|$33

25 532 R1

WASHER, FLAT - 1/4

1шт.

|$34

27 122 R1

NUT, LOCK - 1/4NF

1шт.

|$35

26 030 R1

NUT, HEX - 1/4NF

1шт.

17

BRACKET, BRAKE SUPPORT (SEE PG 04-008)

-29шт.

|$39

-1шт.

|$38

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$40

-1шт.
