Артикул
Название
Примечание
Количество
|$0
6206-71-1251
INJECTION PUMP ASS'Y
SN: 87109-UP
1шт.
|$1
0
INJECTION PUMP ASS'Y
SN: 29222-87108
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
DK101069-9460
PUMP ASS'Y
SN: 87109-UP
1шт.
|$5
DK101069-9260
PUMP ASS'Y
SN: 29222-87108
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131073-8620
HOUSING ASS'Y
SN: 87109-UP
1шт.
1
DK131073-7320
HOUSING ASS'Y
SN: 29222-87108
1шт.
3
DK131400-0100
ADAPTER
SN: 29222-UP
1шт.
4
DK131002-2000
ADAPTER
SN: 29222-UP
1шт.
5
DK131028-6020
COVER
SN: 29222-UP
1шт.
6
DK131011-0800
GASKET
SN: 87109-UP
1шт.
7
DK131017-1000
SCREW
SN: 29222-UP
2шт.
9
DK139206-0400
NUT
SN: 29222-UP
3шт.
11
DK131371-3700
CAMSHAFT
SN: 87109-UP
1шт.
11
DK131371-3400
CAMSHAFT
SN: 29222-87108
1шт.
12
DK028201-7020
BEARING
SN: 29222-UP
-2шт.
13
DK016640-2030
BEARING
SN: 29222-UP
-2шт.
13
DK028202-0020
BEARING
SN: 29222-UP
-2шт.
14
DK131302-1300
RING
SN: 29222-UP
1шт.
16
DK029312-0310
SHIM, 0.10MM
SN: 29222-UP
-2шт.
16
DK029312-0320
SHIM, 0.12MM
SN: 29222-UP
-2шт.
16
DK029312-0330
SHIM, 0.14MM
SN: 29222-UP
-2шт.
16
DK029312-0340
SHIM, 0.16MM
SN: 29222-UP
-2шт.
16
DK029312-0350
SHIM, 0.18MM
SN: 29222-UP
-2шт.
16
DK029312-0360
SHIM, 0.3MM
SN: 29222-UP
-2шт.
16
DK029312-0370
SHIM, 0.5MM
SN: 29222-UP
-2шт.
16
DK029312-0380
SHIM, 1.0MM
SN: 29222-UP
-2шт.
17
DK029311-7010
SHIM, 0.1MM
SN: 29222-UP
-2шт.
17
DK029311-7020
SHIM, 0.12MM
SN: 29222-UP
-2шт.
17
DK029311-7030
SHIM, 0.14MM
SN: 29222-UP
-2шт.
17
DK029311-7040
SHIM, 0.16MM
SN: 29222-UP
-2шт.
17
DK029311-7050
SHIM, 0.18MM
SN: 29222-UP
-2шт.
17
DK029311-7090
SHIM, 0.3MM
SN: 29222-UP
-2шт.
17
DK029311-7060
SHIM, 0.5MM
SN: 29222-UP
-2шт.
17
DK029311-7210
SHIM, 0.7MM
SN: 29222-UP
-2шт.
17
DK029311-7070
SHIM, 1.0MM
SN: 29222-UP
-2шт.
17
DK029311-7220
SHIM, 1.4MM
SN: 29222-UP
-2шт.
17
DK139417-0000
SHIM, 2.40MM
SN: 87109-UP
-2шт.
18
DK131306-1000
BEARING,CENTER
SN: 87109-UP
1шт.
18
DK131306-0800
BEARING,CENTER
SN: 29222-87108
1шт.
19
DK029050-5010
SCREW
SN: 29222-UP
2шт.
20
DK026505-0940
GASKET
SN: 29222-UP
2шт.
22
DK131330-1800
COVER
SN: 29222-UP
1шт.
23
DK020006-2040
BOLT
SN: 29222-UP
4шт.
24
DK131321-1700
GASKET
SN: 29222-UP
1шт.
25
DK029470-4030
KEY
SN: 29222-UP
1шт.
26
DK131401-0020
BOLT,EYE
SN: 87109-UP
1шт.
28
DK131424-7420
VALVE,OVER FLOW
SN: 87109-UP
1шт.
30
DK131508-8920
EYE
SN: 29222-UP
1шт.
|$0
6206-71-1251
INJECTION PUMP ASS'Y
SN: 87109-UP
1шт.
|$1
0
INJECTION PUMP ASS'Y
SN: 29222-87108
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
DK101069-9460
PUMP ASS'Y
SN: 87109-UP
1шт.
|$5
DK101069-9260
PUMP ASS'Y
SN: 29222-87108
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131073-8620
HOUSING ASS'Y
SN: 87109-UP
1шт.
1
DK131073-7320
HOUSING ASS'Y
SN: 29222-87108
1шт.
3
DK131400-0100
ADAPTER
SN: 29222-UP
1шт.
4
DK131002-2000
ADAPTER
SN: 29222-UP
1шт.
5
DK131028-6020
COVER
SN: 29222-UP
1шт.
6
DK131011-0800
GASKET
SN: 87109-UP
1шт.
7
DK131017-1000
SCREW
SN: 29222-UP
2шт.
9
DK139206-0400
NUT
SN: 29222-UP
3шт.
11
DK131371-3700
CAMSHAFT
SN: 87109-UP
1шт.
11
DK131371-3400
CAMSHAFT
SN: 29222-87108
1шт.
12
DK028201-7020
BEARING
SN: 29222-UP
-2шт.
13
DK016640-2030
BEARING
SN: 29222-UP
-2шт.
13
DK028202-0020
BEARING
SN: 29222-UP
-2шт.
14
DK131302-1300
RING
SN: 29222-UP
1шт.
16
DK029312-0310
SHIM, 0.10MM
SN: 29222-UP
-2шт.
16
DK029312-0320
SHIM, 0.12MM
SN: 29222-UP
-2шт.
16
DK029312-0330
SHIM, 0.14MM
SN: 29222-UP
-2шт.
16
DK029312-0340
SHIM, 0.16MM
SN: 29222-UP
-2шт.
16
DK029312-0350
SHIM, 0.18MM
SN: 29222-UP
-2шт.
16
DK029312-0360
SHIM, 0.3MM
SN: 29222-UP
-2шт.
16
DK029312-0370
SHIM, 0.5MM
SN: 29222-UP
-2шт.
16
DK029312-0380
SHIM, 1.0MM
SN: 29222-UP
-2шт.
17
DK029311-7010
SHIM, 0.1MM
SN: 29222-UP
-2шт.
17
DK029311-7020
SHIM, 0.12MM
SN: 29222-UP
-2шт.
17
DK029311-7030
SHIM, 0.14MM
SN: 29222-UP
-2шт.
17
DK029311-7040
SHIM, 0.16MM
SN: 29222-UP
-2шт.
17
DK029311-7050
SHIM, 0.18MM
SN: 29222-UP
-2шт.
17
DK029311-7090
SHIM, 0.3MM
SN: 29222-UP
-2шт.
17
DK029311-7060
SHIM, 0.5MM
SN: 29222-UP
-2шт.
17
DK029311-7210
SHIM, 0.7MM
SN: 29222-UP
-2шт.
17
DK029311-7070
SHIM, 1.0MM
SN: 29222-UP
-2шт.
17
DK029311-7220
SHIM, 1.4MM
SN: 29222-UP
-2шт.
17
DK139417-0000
SHIM, 2.40MM
SN: 87109-UP
-2шт.
18
DK131306-1000
BEARING,CENTER
SN: 87109-UP
1шт.
18
DK131306-0800
BEARING,CENTER
SN: 29222-87108
1шт.
19
DK029050-5010
SCREW
SN: 29222-UP
2шт.
20
DK026505-0940
GASKET
SN: 29222-UP
2шт.
22
DK131330-1800
COVER
SN: 29222-UP
1шт.
23
DK020006-2040
BOLT
SN: 29222-UP
4шт.
24
DK131321-1700
GASKET
SN: 29222-UP
1шт.
25
DK029470-4030
KEY
SN: 29222-UP
1шт.
26
DK131401-0020
BOLT,EYE
SN: 87109-UP
1шт.
28
DK131424-7420
VALVE,OVER FLOW
SN: 87109-UP
1шт.
30
DK131508-8920
EYE
SN: 29222-UP
1шт.
Выбрано товаров: 128
