Запчасти Komatsu 6D95L-1AA-S ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

6206-11-1010

CYLINDER HEAD ASS'Y,WITH VALVE

SN: 29222-UP

1шт.

|$1

6206-11-1100

CYLINDER HEAD ASS'Y,VALVE LESS

SN: 29222-UP

1шт.

1

0

HEAD,CYLINDER

SN: 29222-UP

1шт.

2

6204-19-1310

GUIDE,VALVE

SN: 29222-UP

12шт.

3

6204-11-1440

SEAT,EXHAUST VALVE (STD)

SN: 29222-UP

6шт.

3

6204-19-1440

SEAT, 0.25MM,EXHAUST VALVE (OS)

SN: 29222-UP

6шт.

3

6204-18-1440

SEAT, 0.50MM,EXHAUST VALVE (OS)

SN: 29222-UP

6шт.

4

07046-41008

PLUG

SN: 29222-UP

6шт.

5

07046-41810

PLUG

SN: 29222-UP

13шт.

6

07046-42216

PLUG

SN: 29222-UP

5шт.

7

07046-42516

PLUG

SN: 29222-UP

15шт.

8

02720-40104

PLUG

SN: 29222-UP

1шт.

9

6204-11-8910

PIPE,BREATHER

SN: 29222-UP

3шт.

10

6207-41-4110

VALVE,INTAKE

SN: 29222-UP

6шт.

11

6204-41-4210

VALVE,EXHAUST

SN: 29222-UP

6шт.

12

6204-41-4510

SEAT,SPRING

SN: 29222-UP

12шт.

13

6204-41-4520

COTTER

SN: 29222-UP

24шт.

14

6204-41-4410

SPRING,VALVE

SN: 29222-UP

12шт.

15

6204-41-4540

SEAL,VALVE (K1)

SN: 40633-UP

12шт.

15

6204-41-4540

SEAL,VALVE (K1)

SN: 29222-40632

6шт.

16

6204-41-4550

CAP

SN: 29222-UP

12шт.

17

6207-11-1430

SEAT,INTAKE VALVE (SERVICE PARTS) (STD)

SN: 29222-UP

6шт.

17

6207-19-1430

SEAT, 0.25MM,INTAKE VALVE (SERVICE PARTS) (OS)

SN: 29222-UP

6шт.

17

6207-18-1430

SEAT, 0.50MM,INTAKE VALVE (SERVICE PARTS) (OS)

SN: 29222-UP

6шт.

18

6206-11-1930

HANGER,FRONT

SN: 29222-UP

1шт.

18

6206-11-1950

HANGER,FRONT (WITH TENSION PULLEY)

SN: 29222-UP

1шт.

19

6206-11-1960

HANGER,REAR

SN: 40632-UP

1шт.

19

6206-11-1910

HANGER,REAR

SN: 29222-40631

1шт.

20

01435-01020

BOLT

SN: 29222-UP

4шт.

21

6206-11-1812

GASKET,HEAD (K1)

SN: 40632-UP

1шт.

21

0

GASKET,HEAD (K1)

SN: 29222-40631

1шт.

22

6204-13-1610

BOLT

SN: 40632-UP

25шт.

22

0

BOLT

SN: 29222-40631

25шт.

23

01643-51232

WASHER

SN: 40632-UP

25шт.
