Запчасти Komatsu D31PL-20 МАРКИРОВКА (ЯПОН.)(№77-) МАРКИРОВКА

|1

134-98-11210

PLATE KIT

SN: 46895-48690

1шт.

1

09653-A0480

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 48691-UP

2шт.

|1

0

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 46895-48690

1шт.

2

09653-A0480

PLATE¤ SAFETY,RADIATOR WARNING

SN: 48691-UP

2шт.

|2

0

PLATE¤ SAFETY,RADIATOR WARNING

SN: 46895-48690

1шт.

3

09654-B0640

PLATE¤ SAFETY,BEFORE AND AFTER OPERATION

SN: 48691-UP

1шт.

|3

0

PLATE¤ CAUTION,BEFORE AND AFTER OPERATION

SN: 46895-48690

1шт.

4

09651-A0640

PLATE¤ SAFETY,BEFORE OPERATING

SN: 48691-UP

1шт.

|4

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 46895-48690

1шт.

5

09802-10100

PLATE¤ SAFETY,SAFETY COMFIRM OF REAR

SN: 48691-UP

1шт.

|5

0

PLATE¤ CAUTION,SAFETY COMFIRM OF REAR

SN: 46895-48690

1шт.

6

14X-98-11161

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: 46895-UP

1шт.

7

09652-01101

PLATE¤ CAUTION,FUEL TANK

SN: 46895-UP

1шт.

8

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER

SN: 46895-UP

1шт.

9

103-98-21251

PLATE¤ INSTRUCTION,HYDRAULIC TANK

SN: 46895-UP

1шт.

10

114-98-44250

PLATE¤ OPERATING,PARKING BRAKE LEVER LOCK

SN: 45001-UP

1шт.

11

114-98-44421

PLATE¤ MARK,KOMATSU¤ L.H.

SN: 49042-UP

1шт.

|11

114-98-44420

PLATE¤ MARK,KOMATSU¤ L.H.

SN: 45001-49041

1шт.

|11

114-98-44431

PLATE¤ MARK,KOMATSU¤ R.H.

SN: 49042-UP

1шт.

|11

114-98-44430

PLATE¤ MARK,KOMATSU¤ R.H.

SN: 45001-49041

1шт.

12

09601-00835

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 45001-UP

1шт.

|12

04418-13060

SCREW

SN: 45001-UP

4шт.

13

11G-98-51121

PLATE

SN: 48971-UP

1шт.

|13

11G-98-51120

PLATE¤ DATA

SN: 47617-48970

1шт.

14

11G-C70-9971

PLATE¤ MARK,D31PL

SN: 45001-UP

2шт.

15

09690-C0224

PLATE¤ MARK,KOMATSU

SN: 45001-UP

1шт.

16

11G-98-51111

OIL CHART

SN: 49203-UP

1шт.

|16

11G-98-51110

CHART¤ OIL

SN: 47617-49202

1шт.

17

114-98-44250

PLATE¤ OPERATING,BLADE CONTROL LEVER LOCK

SN: 45001-UP

1шт.

18

11G-98-41410

PLATE¤ OPERATING,BLADE CONTROL LEVER

SN: 45001-UP

1шт.

19

114-98-44250

PLATE¤ OPERATING,T/M CONTROL LEVER LOCK

SN: 45001-UP

1шт.

20

114-98-44170

PLATE¤ OPERATING,STEERING CONTROL LEVER

SN: 45001-UP

1шт.

21

114-98-44180

PLATE¤ OPERATING,STEERING CONTROL LEVER

SN: 45001-UP

1шт.

22

09963-00101

TAG,DO NOT OPERATE

SN: 48936-UP

1шт.

|22

09963-00101

TAG,DO NOT OPERATE

SN: 48691-48935

1шт.

|22

21X-98-21190

TAG¤ CAUTION,DO NOT OPERATE

SN: 46895-48690

1шт.

23

09667-A0480

PLATE¤ SAFETY,ENGINE ROOM

SN: 48691-UP

1шт.

24

09806-B1200

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 48691-UP

2шт.

25

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

SN: 48691-UP

1шт.

26

09669-0000E

PLATE¤ CAUTION

SN: 49475-UP

1шт.
