Артикул
Название
Примечание
Количество
|1
114-15-00036
TRANSMISSION ASS'Y
SN: 42714-UP
1шт.
|1
114-15-00035
TRANSMISSION ASS'Y
SN: 42087-42713
1шт.
|1
114-15-00035
TRANSMISSION ASS'Y,(FOR TWO LEVERS STEERING)
SN: 42087-UP
1шт.
|1
0
TRANSMISSION ASS'Y
SN: 42001-42086
1шт.
|$$5
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-59A0.
-1шт.
|1
114-15-51010
TRANSMISSION ASS'Y
SN: 42714-UP
1шт.
|1
114-15-00511
TRANSMISSION ASS'Y
SN: 42087-42713
1шт.
|1
114-15-00511
TRANSMISSION ASS'Y,(FOR TWO LEVERS STEERING)
SN: 42087-UP
1шт.
|1
0
TRANSMISSION ASS'Y
SN: 42001-42086
1шт.
|$$10
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-55A0 AND F2320-57A0 TO F2320-59A0.
-1шт.
1
363-15-15410
BODY
SN: 42001-UP
1шт.
5
363-15-15470
SPOOL
SN: 42001-UP
1шт.
6
113-15-55450
SPOOL
SN: 42714-UP
1шт.
|6
363-15-15450
SPOOL
SN: 42001-42713
1шт.
|6
363-15-15450
SPOOL,(FOR TWO LEVERS STEERING)
SN: 42001-UP
1шт.
7
09363-00850
YOKE
SN: 42001-UP
2шт.
9
113-15-25481
PLUG
SN: 42001-UP
1шт.
11
113-15-25481
PLUG
SN: 42001-UP
1шт.
|13
124-15-55380
DETENT ASS'Y
SN: 42714-UP
2шт.
|13
103-15-15340
DETENT ASS'Y
SN: 42001-42713
2шт.
|13
103-15-15340
DETENT ASS'Y,(FOR TWO LEVERS STEERING)
SN: 42001-UP
2шт.
14
124-15-55370
SPRING
SN: 42714-UP
1шт.
|14
103-15-15350
SPRING
SN: 42001-42713
1шт.
|14
103-15-15350
SPRING,(FOR TWO LEVERS STEERING)
SN: 42001-UP
1шт.
15
103-15-15330
RETAINER
SN: 42001-UP
1шт.
17
363-15-15510
SPOOL
SN: 42001-UP
1шт.
18
104-15-35170
STOPPER
SN: 42001-UP
1шт.
19
103-15-36160
SPRING
SN: 42001-UP
1шт.
20
363-15-15530
STOPPER
SN: 42001-UP
1шт.
21
103-15-36150
SPRING
SN: 42001-UP
1шт.
22
104-15-36490
SHIM¤ 0.2MM
SN: 42001-UP
4шт.
23
363-15-15520
VALVE
SN: 42001-UP
1шт.
24
22W-75-18890
VALVE
SN: 42001-UP
1шт.
26
22W-75-18880
SLEEVE
SN: 42001-UP
1шт.
27
124-15-45450
PLUG
SN: 42001-UP
1шт.
29
104-15-35230
COVER
SN: 42001-UP
1шт.
32
104-15-36470
SHIM¤ 0.2MM
SN: 42001-UP
6шт.
|32
104-15-36460
SHIM¤ 0.5MM
SN: 42001-UP
4шт.
33
01010-50825
BOLT
SN: 42001-UP
2шт.
|35
103-15-25370
DETENT ASS'Y
SN: 42001-UP
1шт.
35
0
RETAINER
SN: 42001-UP
1шт.
36
0
SPRING
SN: 42001-UP
1шт.
37
0
BALL
SN: 42001-UP
1шт.
|38
363-15-15340
DETENT ASS'Y
SN: 42001-UP
1шт.
38
0
RETAINER
SN: 42001-UP
1шт.
39
0
SPRING
SN: 42001-UP
1шт.
40
0
BALL
SN: 42001-UP
1шт.
42
103-15-45920
GASKET (K3)
SN: 42001-UP
1шт.
Выбрано товаров: 73
