Запчасти Komatsu PC750LC-6K-01 СИЛОВАЯ ПЕРЕДАЧА, 1, 2 И 3 КОЖУХ (№-) СИСТЕМА ОХЛАЖДЕНИЯ

|$0

17M-22-50100

Power Train Assembly

SN: 35021-UP

1шт.

|$1

17M-15-51101

Transmission Assembly

SN: (103375-UP

1шт.

|$2

17M-15-51100

Transmission Assembly

SN: 35021-(103374

1шт.

|$3

17M-15-00231

Housing Assembly

SN: 35021-UP

1шт.

1

Housing

SN: 35021-UP

1шт.

2

568-15-11380

Plug

SN: 35021-UP

1шт.

3

562-15-19230

Seal Ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

4

17M-15-42730

Piston

SN: 35021-UP

1шт.

5

566-15-79260

Seal Ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

6

195-15-48140

Spring

SN: 35021-UP

12шт.

7

232-15-11270

Pin

SN: 35021-UP

6шт.

8

175-15-42880

Spring

SN: 35021-UP

18шт.

9

04020-01434

Pin, Dowel

SN: 35021-UP

2шт.

10

17A-15-22660

Gear, Ring

SN: 35021-UP

1шт.

11

712-82-12710

Disc

SN: 35021-UP

3шт.

12

426-15-22740

Plate

SN: 35021-UP

4шт.

13

17M-15-41141

Housing

SN: 35021-UP

1шт.

14

144-15-22881

Seal Ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

15

17M-15-42771

Piston

SN: 35021-UP

1шт.

16

568-15-12830

Seal Ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

17

07000-72020

O-ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

18

195-15-48140

Spring

SN: 35021-UP

12шт.

19

175-15-42880

Spring

SN: 35021-UP

24шт.

20

04020-01434

Pin, Dowel

SN: 35021-UP

2шт.

21

712-82-12710

Disc

SN: 35021-UP

4шт.

22

426-15-22740

Plate

SN: 35021-UP

5шт.

23

17M-15-41151

Housing

SN: 35021-UP

1шт.

24

425-15-19250

Seal Ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

25

17A-15-22750

Piston

SN: 35021-UP

1шт.

26

566-15-79260

Seal Ring, (Kit : K03, K04)

SN: 35021-UP

1шт.

27

425-15-12920

Spring, L=68.0mm

SN: 35021-UP

12шт.

28

175-15-42880

Spring

SN: 35021-UP

24шт.

29

04020-01434

Pin, Dowel

SN: 35021-UP

2шт.

30

17M-15-42640

Gear, Ring

SN: 35021-UP

1шт.

31

712-82-12710

Disc

SN: 35021-UP

4шт.

32

426-15-22740

Plate

SN: 35021-UP

5шт.
