Запчасти Komatsu PC750LC-6K-01 СИЛОВАЯ ПЕРЕДАЧА, КОРПУС ГИДРОТРАНСФОРМАТОРА (№-) СИСТЕМА ОХЛАЖДЕНИЯ
№
Артикул
Название
Примечание
Количество
|$0
17M-22-50100
Power Train Assembly
SN: 35021-UP
1шт.
|$1
17M-13-51101
Power Piston Assembly
SN: 35021-UP
1шт.
1
17M-13-43211
Case
SN: 35021-UP
1шт.
4
07043-72026
Plug, Taper
SN: 35021-UP
2шт.
6
09607-05080
Plate, Name (Limited Supply)
SN: 35021-UP
1шт.
17
17M-13-21341
Race
SN: 35021-UP
1шт.
23
17M-13-22360
Coupling
SN: 35021-UP
1шт.
24
17M-13-56220
Cover
SN: 35021-UP
1шт.
|$0
17M-22-50100
Power Train Assembly
|$1
17M-13-51101
Power Piston Assembly
1
17M-13-43211
Case
2
07043-70108
Plug
3
07043-71019
Plug
4
07043-72026
Plug, Taper
5
711-66-13140
Sleeve
6
09607-05080
Plate, Name (Limited Supply)
7
04418-13060
Screw
8
17A-13-22550
Sleeve
9
07000-73035
O-ring, (Kit : K01, K02)
10
07000-73038
O-ring, (Kit : K01, K02)
11
04064-09530
Ring, Snap
12
17M-13-22370
Cover
13
07000-75175
O-ring, (Kit : K01, K02)
14
19M-13-23360
Bearing
15
07012-50120
Seal, Oil, (Kit : K01, K02)
16
17M-13-22730
Seal, Dust, (Kit : K01, K02)
17
17M-13-21341
Race
18
17M-13-21770
Spacer
19
711-66-14270
Shim, T=0.15mm, (Kit : K01, K02)
19
711-66-14280
Shim, T=0.2mm, (Kit : K01, K02)
19
711-66-14290
Shim, T=0.5mm, (Kit : K01, K02)
20
07043-70108
Plug
21
01010-81035
Bolt
22
01643-31032
Washer
23
17M-13-22360
Coupling
24
17M-13-56220
Cover
25
17M-13-46210
Gasket, (Kit : K01, K02)
26
01010-81025
Bolt
27
01643-31032
Washer
28
17M-13-42140
Gear
29
17A-13-24490
Bearing
30
04065-07225
Ring, Snap
31
04064-03515
Ring, Snap
Выбрано товаров: 70
