Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
17M-15-51101
TRANSMISSION ASS'Y
SN: (103356)-UP
1шт.
|$6
17M-15-51100
TRANSMISSION ASS'Y
SN: (103135)-(103355)
1шт.
|$7
17M-15-41002
TRANSMISSION ASS'Y
SN: 25178-(103134)
1шт.
|$8
17M-15-41001
TRANSMISSION ASS'Y
SN: 25001-25177
1шт.
|$$6
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-63A0.
-1шт.
|$12
17M-15-55501
T/M VALVE ASS'Y
SN: (103135)-UP
1шт.
|$15
0
T/M VALVE ASS'Y
SN: (25366-25617)
1шт.
|$16
0
T/M VALVE ASS'Y
SN: (101869)-00025365
1шт.
|$17
0
T/M VALVE ASS'Y
SN: (101680)-(101868)
1шт.
|$18
0
T/M VALVE ASS'Y
SN: 25001-(101679)
1шт.
|$$13
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-59A0 TO F2320-61A0.
-1шт.
|$20
17M-15-00323
VALVE ASS'Y
SN: (103135)-UP
1шт.
|$22
17M-15-00321
VALVE ASS'Y
SN: (101680)-(103134)
1шт.
1
0
BODY
SN: (101680)-UP
1шт.
1
0
BODY
SN: 25001-(101679)
1шт.
2
0
SOLENOID
SN: (103278)-UP
2шт.
2
0
SOLENOID
SN: 25001-(103277)
2шт.
3
0
SPOOL
SN: 25618-UP
2шт.
3
0
SPOOL
SN: 25001-25617
2шт.
4
0
SPRING
SN: 25001-UP
2шт.
5
0
SHIM, 0.5MM
SN: 25001-UP
8шт.
6
0
SHIM, 0.2MM
SN: 25001-UP
8шт.
7
0
PLUG
SN: 25001-UP
2шт.
8
0
VALVE
SN: 25001-UP
2шт.
9
0
BALL
SN: 25001-UP
2шт.
10
0
O-RING
SN: 25001-UP
2шт.
13
195-15-76410
BOLT
SN: (101680)-UP
4шт.
Выбрано товаров: 35
