Запчасти Komatsu S6D170-1L-6W СТАРТЕР (KW) (ВНУТР. ЧАСТИ)(№7-) ДВИГАТЕЛЬ

|$1

600-813-8110

STARTING MOTOR ASS'Y,(11KW)

SN: 15295-UP

1шт.

|$$2

THE SAWAFUJI DENKI PART NUMBER IS THAT SD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

SD1310-10010X0

YOKE ASS'Y

SN: 15295-UP

1шт.

2

SD4141-26400X0

PACKING

SN: 15295-UP

2шт.

3

SD2240-24160X0

BRACKET,REAR

SN: 15295-UP

1шт.

4

SD1331-04300X0

BRUSH HOLDER ASS'Y

SN: 15295-UP

1шт.

5

SD5250-02800X0

SPRING,BRUSH

SN: 15295-UP

4шт.

6

SD5000-10500X0

SCREW

SN: 15295-UP

2шт.

7

SD6414-04510X0

O-RING

SN: 15295-UP

2шт.

8

SD3040-12100X0

PLATE

SN: 15295-UP

1шт.

9

SD1320-07820X0

ARMATURE ASS'Y

SN: 15295-UP

1шт.

10

SD6206-01250X0

BEARING,BALL

SN: 15295-UP

1шт.

11

SD6206-01240X0

BEARING,BALL

SN: 15295-UP

1шт.

12

SD8167-0719060

BOLT

SN: 15295-UP

2шт.

13

SD2245-00830X0

CASE,GEAR

SN: 15295-UP

1шт.

14

SD5031-05700X0

SHIM

SN: 15295-UP

1шт.

15

SD2441-03200X0

SHAFT

SN: 15295-UP

1шт.

16

SD2244-06902X0

HOLDER,CENTER

SN: 15295-UP

1шт.

17

SD6410-01900X0

SEAL,OIL

SN: 15295-UP

1шт.

18

SD6206-01260X0

BEARING,BALL

SN: 15295-UP

1шт.

19

SD1361-04700X0

PINION CLUTCH ASS'Y

SN: 15295-UP

1шт.

20

SD3661-02000X0

STOPPER,PINION

SN: 15295-UP

1шт.

21

SD5221-01200X0

HOOK

SN: 15295-UP

2шт.

22

SD5058-04200X0

RING,RETAINING

SN: 15295-UP

1шт.

23

SD5010-27430X0

BOLT

SN: 15295-UP

1шт.

24

SD4141-26301X0

PACKING

SN: 15295-UP

1шт.

25

SD1372-04200X0

LEVER ASS'Y

SN: 15295-UP

1шт.

26

SD3600-17800X0

ROD

SN: 15295-UP

1шт.

27

SD4223-05200X0

HOLDER,LEVER

SN: 15295-UP

2шт.

28

SD5201-10100X0

COIL,SPRING

SN: 15295-UP

1шт.

29

SD2407-02101X0

COLLAR

SN: 15295-UP

1шт.

30

SD2244-06831X0

BRACKET,CENTER

SN: 15295-UP

1шт.

31

SD2046-14210X9

CASE ASS'Y,PINION

SN: 15295-UP

1шт.

32

SD2620-10500X9

METAL

SN: 15295-UP

1шт.

33

SD5010-26200X0

BOLT

SN: 15295-UP

6шт.

34

SD1350-10900X9

SWITCH ASS'Y,ENGAGE

SN: 15295-UP

1шт.

35

SD5010-27300X0

BOLT

SN: 15295-UP

2шт.

36

SD0590-0012040

RELAY,SAFETY

SN: 15295-UP

1шт.

37

SD1331-04300X9

BRUSH HOLDER ASS'Y,(SERVICE PARTS)

SN: 15295-UP

1шт.

38

SD5250-02800X0

SPRING,BRUSH

SN: 15295-UP

4шт.

39

SD2660-07400X6

BRUSH,(FOR 1ST SERVICE ONLY)

SN: 15295-UP

1шт.

40

SD2660-07400X7

BRUSH,(FROM 2ND SERVICE)

SN: 15295-UP

4шт.

|$1

600-813-8110

STARTING MOTOR ASS'Y,(11KW)

SN: 15295-UP

1шт.

|$$2

THE SAWAFUJI DENKI PART NUMBER IS THAT SD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

SD1310-10010X0

YOKE ASS'Y

SN: 15295-UP

1шт.

2

SD4141-26400X0

PACKING

SN: 15295-UP

2шт.

3

SD2240-24160X0

BRACKET,REAR

SN: 15295-UP

1шт.

4

SD1331-04300X0

BRUSH HOLDER ASS'Y

SN: 15295-UP

1шт.

5

SD5250-02800X0

SPRING,BRUSH

SN: 15295-UP

4шт.

6

SD5000-10500X0

SCREW

SN: 15295-UP

2шт.

7

SD6414-04510X0

O-RING

SN: 15295-UP

2шт.

8

SD3040-12100X0

PLATE

SN: 15295-UP

1шт.

9

SD1320-07820X0

ARMATURE ASS'Y

SN: 15295-UP

1шт.

10

SD6206-01250X0

BEARING,BALL

SN: 15295-UP

1шт.

11

SD6206-01240X0

BEARING,BALL

SN: 15295-UP

1шт.

12

SD8167-0719060

BOLT

SN: 15295-UP

2шт.

13

SD2245-00830X0

CASE,GEAR

SN: 15295-UP

1шт.

14

SD5031-05700X0

SHIM

SN: 15295-UP

1шт.

15

SD2441-03200X0

SHAFT

SN: 15295-UP

1шт.

16

SD2244-06902X0

HOLDER,CENTER

SN: 15295-UP

1шт.

17

SD6410-01900X0

SEAL,OIL

SN: 15295-UP

1шт.

18

SD6206-01260X0

BEARING,BALL

SN: 15295-UP

1шт.

19

SD1361-04700X0

PINION CLUTCH ASS'Y

SN: 15295-UP

1шт.

20

SD3661-02000X0

STOPPER,PINION

SN: 15295-UP

1шт.

21

SD5221-01200X0

HOOK

SN: 15295-UP

2шт.

22

SD5058-04200X0

RING,RETAINING

SN: 15295-UP

1шт.

23

SD5010-27430X0

BOLT

SN: 15295-UP

1шт.

24

SD4141-26301X0

PACKING

SN: 15295-UP

1шт.

25

SD1372-04200X0

LEVER ASS'Y

SN: 15295-UP

1шт.

26

SD3600-17800X0

ROD

SN: 15295-UP

1шт.

27

SD4223-05200X0

HOLDER,LEVER

SN: 15295-UP

2шт.

28

SD5201-10100X0

COIL,SPRING

SN: 15295-UP

1шт.

29

SD2407-02101X0

COLLAR

SN: 15295-UP

1шт.

30

SD2244-06831X0

BRACKET,CENTER

SN: 15295-UP

1шт.

31

SD2046-14210X9

CASE ASS'Y,PINION

SN: 15295-UP

1шт.

32

SD2620-10500X9

METAL

SN: 15295-UP

1шт.

33

SD5010-26200X0

BOLT

SN: 15295-UP

6шт.

34

SD1350-10900X9

SWITCH ASS'Y,ENGAGE

SN: 15295-UP

1шт.

35

SD5010-27300X0

BOLT

SN: 15295-UP

2шт.

36

SD0590-0012040

RELAY,SAFETY

SN: 15295-UP

1шт.

37

SD1331-04300X9

BRUSH HOLDER ASS'Y,(SERVICE PARTS)

SN: 15295-UP

1шт.

38

SD5250-02800X0

SPRING,BRUSH

SN: 15295-UP

4шт.

39

SD2660-07400X6

BRUSH,(FOR 1ST SERVICE ONLY)

SN: 15295-UP

1шт.

40

SD2660-07400X7

BRUSH,(FROM 2ND SERVICE)

SN: 15295-UP

4шт.
